CPU
PGA 423 Socket Intel® Pentium® 4
100/105*/110*/133* MHz FSB (400MHz data bus, 200MHz address bus frequency)
AUTO detect CPU voltage
Chipset
North Bridge:
Intel® 850 AGPset + ICH2
Super I/O: Winbond W83627HF
Creative CT5880 PCI
Memory
4 x RIMM slots; Dual RAMBUS channel support
Supports ECC Type RIMM Module
64MB - 2GB
Supports 64/128/256/512 MB RAMBUS RIMM modules
Expansion Slots
1 x AGP Pro, 1 x CNR (Communication Networking Riser)
5 x PCI slots (PCI 2.2 compliant)
H/W Monitoring
H/W detect +/-5V, +/-12V, CPU voltage CMOS battery Status
3 Fan Power Speed Detection Connectors
Auto speed down and Alarm when CPU overheat or Fan failure
BIOS
Supports DualBIOS™
IDE#1~#4, SCSI, LS120, ZIP CD-ROM bootable
FWH(Firm Ware Hub) ROM BIOS with enhanced ACPI feature for PC99/Win98/WinME/Win2000 compliance, Green, PnP, DMI, INT13 (>8.4GB) Anti-Virus functions
Supports @BIOS™ Live Update utility
Auto-detect report system health status
Unique Features
STR (Suspend-To-RAM)
Wake-on-LAN (WOL),Wake-On-Ring (WOR)
Poly fuse for keyboard, USB game overcurrent protection
Bundle Software
GIGABYTE Windows Utility Manager
Power
Power-on by Keyboard, PS/2 Mouse, LAN, RTC, Modem Switch
Suspend/Wake-on by ACPI APM device
ATX power connector, ATX 12V connector, 3.3V AUX power connector
Power-off by Windows ® 98/ME/2000 shut down switch
Supports USB device wake-up
AC recovery ON/OFF control; 3 level ACPI LED support
Form Factor
ATX, 6 layers PCB, 305mm x 244mm
Driver
Creative PCI audio drivers
I/O
2 x UDMA ATA 33/66/100 Bus Master IDE
1 x FDD, 2 x COM, 1 x LPT, PS/2 Keyboard, PS/2 Mouse on board
1 x Joystic, 1 x Line-in, 1 x Line-out, 1 x MIC
2 x USB ports on board, 2 x USB ports by cable (optional)
IrDA header ready
