Intel Xeon 5130

Specifications

-Essentials
Status Launched
Launch Date Q2'06
Processor Number 5130
Cache 4 MB L2
Bus Speed 1333 MHz FSB
FSB Parity Yes
Instruction Set 64-bit
Embedded Options Available Yes
Lithography 65 nm
VID Voltage Range B2=1.00V-1.50V
Recommended Customer Price N/A
Datasheet Link
-Performance
# of Cores 2
Processor Base Frequency 2 GHz
TDP 65 W
Scenario Design Power (SDP) 0 W
-Package Specifications
TCASE 65°C
Package Size 37.5mm x 37.5mm
Processing Die Size 143 mm2
# of Processing Die Transistors 291 million
Low Halogen Options Available See MDDS
-Advanced Technologies
Intel® Turbo Boost Technology ‡ No
Intel® Hyper-Threading Technology ‡ No
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ No
Intel® 64 ‡ Yes
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Intel® Demand Based Switching No
Thermal Monitoring Technologies Yes
-Intel® Platform Protection Technology
Trusted Execution Technology ‡ No
Execute Disable Bit ‡ Yes
