Popis
CPU ⢠Supports 64-bit AMD® Athlon⢠64, Sempron⢠and Turion⢠64 processor (Socket 754) ⢠Supports up to 3700+ Athlon 64, or higher CPUChipset ⢠NVIDIA® nForce3 250 Chipset- Supports Athlon⢠64 processor (Socket 754), 800MHz Hypertransport interface.- Supports single memory channels, DDR 400/333/266 without ECC support.- Supports external AGP 4X/8X- Integrated Serial ATA interface and dual channel ATA 133/100 master mode EIDE controller.- Supports 8 high speed USB2.0 ports.- AC'97 2.3 compliance. MSI Reminds You...1. Because of the limitations of chipset, this MB does not support Win98/ME.2. Please use MSI Live BIOS tool to upgrade BIOS of this product. gt;
Main Memory
⢠Supports 2 slots for 184-pin DDR DRAM DIMM modules.⢠Supports DDR 400/333/266.⢠Supports memory size up to 2GB without ECC.
Slots ⢠One AGP (Accelerated Graphics Port) 1.5V 4X/8X slot⢠Five 32-bit v2.3 Master PCI bus slots (support 3.3v/5v PCI bus interface).
On-Board IDE/SATA
⢠An IDE controller on the NVIDIA nForce3 250 chipset provides IDE HDD/CD-ROM with PIO, Bus Master and Ultra DMA133/100/66 operation modes.- Can connect up to 4 IDE devices.
⢠Integrated SATA, supporting up to 2 ports.- Up to 150MB/s transfer rate.- One SATA controller, supporting 2 drives in master mode.
NV RAID (Software)⢠Supports 2 serial ATA + 4 ATA 133- RAID 0 or 1, 0+1, JBOD is supported- Booting from RAID- Cross controller RAID support- Rebuilding on the fly- Spare Disk Allocation⢠Supports Windows 2000 and later versionsMSI Reminds You...⢠The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk.
Audio ⢠5.1 channel audio codec RealTek ALC655.- Compliance with AC97 v2.3 Spec.- Meet PC2001 audio performance requirement.
LAN
⢠Realtek® 8100C and 8110SB - Supports 10Mb/s, 100Mb/s and 1000Mb/s auto-negotiation operation.- Compliant with PCI v2.2.- Supports ACPI Power Management.NOTE:Realtek 8100C available in K8N Neo-V V2.0Realtek 8110SB available in K8N Neo-FSR V2.0
Internal I/O Connectors- ATX 20-Pin power connector- 4-pin ATX 12V power connector- CPU / System x 2 / Chipset FAN connectors- Serial port header (COM2) - CD-in connector- Clear CMOS jumper- IrDA infrared module header- Chassis intrusion switch connector - 1 x Floppy disk drive connector- 2 x Serial ATA connectors- 2 x ATA133 IDE drive connectors- 2 x USB 2.0 connectors support additional 4 ports - Front panel audio connector- Front panel connector
Back Panel I/O Ports - 1 x Parallel- 1 x Serial port (COM 1) - 1 x PS/2 Keyboard - 1 x PS/2 Mouse - 1 x 3 in 1 Audio jack (Line-in/Line-out/MIC)- 4 x USB 2.0 - 1 x RJ45 LAN Jack
Main Memory
⢠Supports 2 slots for 184-pin DDR DRAM DIMM modules.⢠Supports DDR 400/333/266.⢠Supports memory size up to 2GB without ECC.
Slots ⢠One AGP (Accelerated Graphics Port) 1.5V 4X/8X slot⢠Five 32-bit v2.3 Master PCI bus slots (support 3.3v/5v PCI bus interface).
On-Board IDE/SATA
⢠An IDE controller on the NVIDIA nForce3 250 chipset provides IDE HDD/CD-ROM with PIO, Bus Master and Ultra DMA133/100/66 operation modes.- Can connect up to 4 IDE devices.
⢠Integrated SATA, supporting up to 2 ports.- Up to 150MB/s transfer rate.- One SATA controller, supporting 2 drives in master mode.
NV RAID (Software)⢠Supports 2 serial ATA + 4 ATA 133- RAID 0 or 1, 0+1, JBOD is supported- Booting from RAID- Cross controller RAID support- Rebuilding on the fly- Spare Disk Allocation⢠Supports Windows 2000 and later versionsMSI Reminds You...⢠The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk.
Audio ⢠5.1 channel audio codec RealTek ALC655.- Compliance with AC97 v2.3 Spec.- Meet PC2001 audio performance requirement.
LAN
⢠Realtek® 8100C and 8110SB - Supports 10Mb/s, 100Mb/s and 1000Mb/s auto-negotiation operation.- Compliant with PCI v2.2.- Supports ACPI Power Management.NOTE:Realtek 8100C available in K8N Neo-V V2.0Realtek 8110SB available in K8N Neo-FSR V2.0
Internal I/O Connectors- ATX 20-Pin power connector- 4-pin ATX 12V power connector- CPU / System x 2 / Chipset FAN connectors- Serial port header (COM2) - CD-in connector- Clear CMOS jumper- IrDA infrared module header- Chassis intrusion switch connector - 1 x Floppy disk drive connector- 2 x Serial ATA connectors- 2 x ATA133 IDE drive connectors- 2 x USB 2.0 connectors support additional 4 ports - Front panel audio connector- Front panel connector
Back Panel I/O Ports - 1 x Parallel- 1 x Serial port (COM 1) - 1 x PS/2 Keyboard - 1 x PS/2 Mouse - 1 x 3 in 1 Audio jack (Line-in/Line-out/MIC)- 4 x USB 2.0 - 1 x RJ45 LAN Jack
