General
Model number
2007WFP
Flat Panel
Screen type
Active matrix - TFT LCD
Screen dimensions
20.1 inches (20.1-inch viewable image size)
Preset display area:
Horizontal
433.4 mm (17.0 inches)
Vertical
270.9 mm (10.7 inches)
Pixel pitch
0.258 mm
Viewing angle
+/- 89° (vertical) typ, +/- 89° (horizontal) typ
Luminance output
300 cd/m ²(typ)
Contrast ratio
800:1 (typ)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
CCFL (6) edgelight system
Response Time
16ms typical
Resolution
Horizontal scan range
30 kHz to 81 kHz (automatic)
Vertical scan range
56 Hz to 76 Hz, exception 1680 x 1050 at 60 Hz only
Optimal preset resolution
1680 x 1050 at 60 Hz
Highest preset resolution
1680 x 1050 at 60 Hz
Video Supported Modes
Video display capabilities (DVI playback)
480p/576p/720p (Supports HDCP)
Video display capabilities (Composite playback)
NTSC/PAL
Video display capabilities (S-Video playback)
NTSC/PAL
