Popis
Display
Diagonal Size: 15"
Viewable Size: 15"
Dot Pitch / Pixel Pitch: 0.3 mm
Max Resolution: 1024 x 768 / 75 Hz
Colour support: 24-bit (16.7 million colours)
Max Sync Rate (V x H): 75 Hz x 60 kHz, 75.1 Hz x 60 kHz
Front Panel Controls: Power on/off, audio volume, speaker on/off, adjust +/- , select, Power on/off, reset settings, adjust +/- , select, menu, Power on/off, contrast, brightness, audio volume, auto-configuration, Power on/off, adjust +/- , menu, Power on/off, menu, mute
On-Screen Controls: Contrast, brightness, H/V-position, H/V-size, language select, OSD-position, colour temperature selection, audio bass, audio treble, audio balance equalizer, image auto-centering, Contrast, brightness, H/V-position, H/V-size, language select, colour temperature selection, audio volume, Contrast, brightness, H/V-position, H/V-size, language select, colour temperature selection, audio bass, audio treble, audio volume, H/V-position, language select, OSD-position, audio bass, audio treble, reset settings, audio balance equalizer, OSD time, Contrast, brightness, H/V-position, H/V-size, language select, OSD-position, colour temperature selection, Contrast, brightness, H/V-position, H/V-size, language select, colour adjustment, Contrast, brightness, language select, colour adjustment, auto-configuration, fine tune, Contrast, brightness, H/V-position, H/V-size, language select, OSD-position, colour temperature selection, audio bass, audio treble, image auto-centering, Contrast, brightness, H/V-position, H/V-size, language select, colour adjustment, auto-configuration
Factory Preset Resolution Modes:
640 x 480 / 75 Hz
800 x 600 / 75 Hz
832 x 624 / 75 Hz
1024 x 768 / 75 Hz, 640 x 480 / 75 Hz
640 x 480 / 60 Hz
720 x 400 / 70 Hz
800 x 600 / 56 Hz
800 x 600 / 75 Hz
832 x 624 / 75 Hz
1024 x 768 / 75 Hz
1024 x 768 / 60 Hz, 1024 x 768 / 75 Hz
832 x 764 / 75 Hz
800 x 600 / 75 Hz
640 x 480 / 75 Hz, 640 x 480 / 60 Hz
640 x 480 / 75 Hz
800 x 600 / 56 Hz
800 x 600 / 75 Hz
832 x 624 / 75 Hz
1024 x 768 / 60 Hz
1024 x 768 / 75 Hz, 720 x 400
640 x 480 / 60 Hz
640 x 480 / 75 Hz
800 x 600 / 56 Hz
800 x 600 / 75 Hz
832 x 624 / 75 Hz
1024 x 768 / 60 Hz
1024 x 1024 / 75 Hz, 1024 x 768 / 60 Hz
1024 x 768 / 75 Hz
832 x 624 / 75 Hz
800 x 600 / 56 Hz
800 x 600 / 75 Hz
640 x 480 / 60 Hz
640 x 480 / 75 Hz
720 x 400
Features: Anti-glare, Anti-glare, anti-static, anti-reflective
Controls / Adjustments: Bass, treble, volume, brightness, contrast, H/V position, H/V size, colour temperature
Video Bandwidth: 78.8 MHz
Image Colour Temperature: Adjustable
Image Contrast Ratio: 200:1, 350:1
Image Max H-View Angle: +60 / -60
Image Max V-View Angle: +45 / -55, +50 / -50
Image Aspect Ratio: 4:3
Image Brightness: 200 cd/m2
Video input
Analogue video Signal: RGB
Digital Video Standard: Digital Visual Interface (DVI), Digital Flat Panel (DFP), Digital Visual Interface (DVI)
Manufacturer's product description
NEC Technologies, the first to offer a complete line of Plug and Play compatible monitors, has created display monitors that have come to represent the best of the best. The MultiSync monitor group offers a complete line of monitors with the features and performance you need to get the most out of today's powerful software - from home edutainment to sophisticated high-end applications. Ideal for financial, medical, manufacturing, transportation or corporate workplaces, the MultiSync LCD1525M multimedia monitor delivers exceptional image quality combined with outstanding multimedia capabilities in a slim, lightweight package. The four-port USB hub allows fast and easy connections for true Plug and Play convenience.
Audio output
Type: Speaker(s) - integrated
Sound Output Mode: Stereo
Output Power / Channel: 1 Watt
Response Bandwidth: 80 - 20000 Hz
Audio Amplifier: Integrated
Expansion / connectivity
Interfaces:
1 x headphones - output - mini-phone stereo 3.5 mm - 1
4 x USB - 4 PIN USB Type A - 4, 4 x USB - 4 PIN USB Type A - 4
1 x headphones - output - mini-phone stereo 3.5 mm - 1, 4 x USB - 4 PIN USB Type A - 4
Connections:
1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x USB - 4 PIN USB Type B - 1
1 x audio - line-out - mini-phone stereo 3.5 mm - 1, 1 x audio - line-out - mini-phone stereo 3.5 mm - 1
1 x USB - 4 PIN USB Type B - 1
1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1, 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x audio - line-out - mini-phone stereo 3.5 mm - 1
1 x USB - 4 PIN USB Type B - 1, 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x display / video - DVI-Digital - 1
1 x USB - 4 PIN USB Type B - 1, 1 x USB - 4 PIN USB Type B - 1
1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1, 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x USB - 4 PIN USB Type B - 1
1 x headphones - output - mini-phone stereo 3.5 mm - 1
Miscellaneous
Cables Included:
1 x display cable
1 x serial cable
1 x A/V cable, 1 x display cable, 1 x video cable - 1.8 m
1 x USB cable
1 x audio cable, 1 x display cable
1 x USB cable, 1 x display cable
1 x audio cable, 1 x power cable
2 x display cable, 1 x video cable - 1.8 m
1 x USB cable, 1 x display cable - 1.8 m, 1 x display cable
1 x USB cable
1 x audio cable, 1 x A/V cable
1 x serial cable
1 x display cable
Compliant Standards: Plug and Play, FCC Class B certified, CE, TUV, TUV GS, EPA Energy Star, ISO 9241, NEMKO, SEMKO, TCO '95, Plug and Play, FCC Class B certified, MPR II, CSA, UL, DHHS, DOC-B, EPA Energy Star, ISO 9241, Plug and Play, FCC Class B certified, CE, MPR II, CSA, UL, TUV, TUV GS, CISPR 22 Class B, cUL, DDC-1, DDC-2B, DEMKO, DHHS, EPA Energy Star, FEMKO, ISO 9241, NEMKO, NUTEK, SEMKO, TCO '99, Plug and Play, FCC Class B certified, MPR II, CSA, UL, DHHS, EPA Energy Star, ISO 9241, Plug and Play, FCC Class B certified, CE, UL, TUV, TUV GS, CISPR 22 Class B, cUL, DEMKO, DOC-B, EPA Energy Star, FEMKO, ISO 9241, NEMKO, NUTEK, SEMKO, TCO '95, Plug and Play, FCC Class B certified, MPR II, CSA, UL, DHHS, EPA Energy Star, NUTEK, TCO '99, Plug and Play, CE, TUV, TUV GS, EPA Energy Star, ISO 13406-2, TCO '99, Plug and Play, FCC Class B certified, CE, CSA, UL, TUV, TUV GS, DEMKO, DHHS, DOC-B, EPA Energy Star, FEMKO, ISO 9241, MPR III, NUTEK, SEMKO, Plug and Play, FCC Class B certified, CE, MPR II, CSA, UL, TUV, TUV GS, DDC-1, DDC-2B, DHHS, EPA Energy Star, NUTEK, TCO '99, VESA DPMS
Features: Security lock slot (cable lock sold separately)
Power
Form Factor: Integrated
Voltage Required: AC 110/220 V ± 10% ( 50/60 Hz ), AC 100/240 V ( 50/60 Hz ), AC 110/240 V ± 10% ( 50/60 Hz ), AC 110/230 V ± 10% ( 50/60 Hz )
Power Consumption Operational: 45 Watt
Power Consumption Stand by / Sleep: 5 Watt
Software / system requirements
Software Included: Drivers amp; Utilities
Manufacturer warranty
Service amp; Support: 3 years warranty
Service amp; Support Details: Limited warranty - parts and labour - 3 years - carry-in, Limited warranty - parts and labour - 3 years
Environmental parameters
Min Operating Temperature: 5 °C
Max Operating Temperature: 35 °C
Max Altitude Operating: 3 km
Humidity Range Operating: 30 - 80%, 20 - 80%, 0 - 85%
Diagonal Size: 15"
Viewable Size: 15"
Dot Pitch / Pixel Pitch: 0.3 mm
Max Resolution: 1024 x 768 / 75 Hz
Colour support: 24-bit (16.7 million colours)
Max Sync Rate (V x H): 75 Hz x 60 kHz, 75.1 Hz x 60 kHz
Front Panel Controls: Power on/off, audio volume, speaker on/off, adjust +/- , select, Power on/off, reset settings, adjust +/- , select, menu, Power on/off, contrast, brightness, audio volume, auto-configuration, Power on/off, adjust +/- , menu, Power on/off, menu, mute
On-Screen Controls: Contrast, brightness, H/V-position, H/V-size, language select, OSD-position, colour temperature selection, audio bass, audio treble, audio balance equalizer, image auto-centering, Contrast, brightness, H/V-position, H/V-size, language select, colour temperature selection, audio volume, Contrast, brightness, H/V-position, H/V-size, language select, colour temperature selection, audio bass, audio treble, audio volume, H/V-position, language select, OSD-position, audio bass, audio treble, reset settings, audio balance equalizer, OSD time, Contrast, brightness, H/V-position, H/V-size, language select, OSD-position, colour temperature selection, Contrast, brightness, H/V-position, H/V-size, language select, colour adjustment, Contrast, brightness, language select, colour adjustment, auto-configuration, fine tune, Contrast, brightness, H/V-position, H/V-size, language select, OSD-position, colour temperature selection, audio bass, audio treble, image auto-centering, Contrast, brightness, H/V-position, H/V-size, language select, colour adjustment, auto-configuration
Factory Preset Resolution Modes:
640 x 480 / 75 Hz
800 x 600 / 75 Hz
832 x 624 / 75 Hz
1024 x 768 / 75 Hz, 640 x 480 / 75 Hz
640 x 480 / 60 Hz
720 x 400 / 70 Hz
800 x 600 / 56 Hz
800 x 600 / 75 Hz
832 x 624 / 75 Hz
1024 x 768 / 75 Hz
1024 x 768 / 60 Hz, 1024 x 768 / 75 Hz
832 x 764 / 75 Hz
800 x 600 / 75 Hz
640 x 480 / 75 Hz, 640 x 480 / 60 Hz
640 x 480 / 75 Hz
800 x 600 / 56 Hz
800 x 600 / 75 Hz
832 x 624 / 75 Hz
1024 x 768 / 60 Hz
1024 x 768 / 75 Hz, 720 x 400
640 x 480 / 60 Hz
640 x 480 / 75 Hz
800 x 600 / 56 Hz
800 x 600 / 75 Hz
832 x 624 / 75 Hz
1024 x 768 / 60 Hz
1024 x 1024 / 75 Hz, 1024 x 768 / 60 Hz
1024 x 768 / 75 Hz
832 x 624 / 75 Hz
800 x 600 / 56 Hz
800 x 600 / 75 Hz
640 x 480 / 60 Hz
640 x 480 / 75 Hz
720 x 400
Features: Anti-glare, Anti-glare, anti-static, anti-reflective
Controls / Adjustments: Bass, treble, volume, brightness, contrast, H/V position, H/V size, colour temperature
Video Bandwidth: 78.8 MHz
Image Colour Temperature: Adjustable
Image Contrast Ratio: 200:1, 350:1
Image Max H-View Angle: +60 / -60
Image Max V-View Angle: +45 / -55, +50 / -50
Image Aspect Ratio: 4:3
Image Brightness: 200 cd/m2
Video input
Analogue video Signal: RGB
Digital Video Standard: Digital Visual Interface (DVI), Digital Flat Panel (DFP), Digital Visual Interface (DVI)
Manufacturer's product description
NEC Technologies, the first to offer a complete line of Plug and Play compatible monitors, has created display monitors that have come to represent the best of the best. The MultiSync monitor group offers a complete line of monitors with the features and performance you need to get the most out of today's powerful software - from home edutainment to sophisticated high-end applications. Ideal for financial, medical, manufacturing, transportation or corporate workplaces, the MultiSync LCD1525M multimedia monitor delivers exceptional image quality combined with outstanding multimedia capabilities in a slim, lightweight package. The four-port USB hub allows fast and easy connections for true Plug and Play convenience.
Audio output
Type: Speaker(s) - integrated
Sound Output Mode: Stereo
Output Power / Channel: 1 Watt
Response Bandwidth: 80 - 20000 Hz
Audio Amplifier: Integrated
Expansion / connectivity
Interfaces:
1 x headphones - output - mini-phone stereo 3.5 mm - 1
4 x USB - 4 PIN USB Type A - 4, 4 x USB - 4 PIN USB Type A - 4
1 x headphones - output - mini-phone stereo 3.5 mm - 1, 4 x USB - 4 PIN USB Type A - 4
Connections:
1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x USB - 4 PIN USB Type B - 1
1 x audio - line-out - mini-phone stereo 3.5 mm - 1, 1 x audio - line-out - mini-phone stereo 3.5 mm - 1
1 x USB - 4 PIN USB Type B - 1
1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1, 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x audio - line-out - mini-phone stereo 3.5 mm - 1
1 x USB - 4 PIN USB Type B - 1, 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x display / video - DVI-Digital - 1
1 x USB - 4 PIN USB Type B - 1, 1 x USB - 4 PIN USB Type B - 1
1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1, 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1
1 x USB - 4 PIN USB Type B - 1
1 x headphones - output - mini-phone stereo 3.5 mm - 1
Miscellaneous
Cables Included:
1 x display cable
1 x serial cable
1 x A/V cable, 1 x display cable, 1 x video cable - 1.8 m
1 x USB cable
1 x audio cable, 1 x display cable
1 x USB cable, 1 x display cable
1 x audio cable, 1 x power cable
2 x display cable, 1 x video cable - 1.8 m
1 x USB cable, 1 x display cable - 1.8 m, 1 x display cable
1 x USB cable
1 x audio cable, 1 x A/V cable
1 x serial cable
1 x display cable
Compliant Standards: Plug and Play, FCC Class B certified, CE, TUV, TUV GS, EPA Energy Star, ISO 9241, NEMKO, SEMKO, TCO '95, Plug and Play, FCC Class B certified, MPR II, CSA, UL, DHHS, DOC-B, EPA Energy Star, ISO 9241, Plug and Play, FCC Class B certified, CE, MPR II, CSA, UL, TUV, TUV GS, CISPR 22 Class B, cUL, DDC-1, DDC-2B, DEMKO, DHHS, EPA Energy Star, FEMKO, ISO 9241, NEMKO, NUTEK, SEMKO, TCO '99, Plug and Play, FCC Class B certified, MPR II, CSA, UL, DHHS, EPA Energy Star, ISO 9241, Plug and Play, FCC Class B certified, CE, UL, TUV, TUV GS, CISPR 22 Class B, cUL, DEMKO, DOC-B, EPA Energy Star, FEMKO, ISO 9241, NEMKO, NUTEK, SEMKO, TCO '95, Plug and Play, FCC Class B certified, MPR II, CSA, UL, DHHS, EPA Energy Star, NUTEK, TCO '99, Plug and Play, CE, TUV, TUV GS, EPA Energy Star, ISO 13406-2, TCO '99, Plug and Play, FCC Class B certified, CE, CSA, UL, TUV, TUV GS, DEMKO, DHHS, DOC-B, EPA Energy Star, FEMKO, ISO 9241, MPR III, NUTEK, SEMKO, Plug and Play, FCC Class B certified, CE, MPR II, CSA, UL, TUV, TUV GS, DDC-1, DDC-2B, DHHS, EPA Energy Star, NUTEK, TCO '99, VESA DPMS
Features: Security lock slot (cable lock sold separately)
Power
Form Factor: Integrated
Voltage Required: AC 110/220 V ± 10% ( 50/60 Hz ), AC 100/240 V ( 50/60 Hz ), AC 110/240 V ± 10% ( 50/60 Hz ), AC 110/230 V ± 10% ( 50/60 Hz )
Power Consumption Operational: 45 Watt
Power Consumption Stand by / Sleep: 5 Watt
Software / system requirements
Software Included: Drivers amp; Utilities
Manufacturer warranty
Service amp; Support: 3 years warranty
Service amp; Support Details: Limited warranty - parts and labour - 3 years - carry-in, Limited warranty - parts and labour - 3 years
Environmental parameters
Min Operating Temperature: 5 °C
Max Operating Temperature: 35 °C
Max Altitude Operating: 3 km
Humidity Range Operating: 30 - 80%, 20 - 80%, 0 - 85%
