Popis
CPU
AMD AM3/AM2+/AM2 ;Phenomâ¢II /Athlonâ¢II /Phenom⢠/ Athlon⢠/Sempron⢠Processors
AMD Cool 'n' Quiet⢠Technology
CPU Power up to 95W
Chipset
NVIDIA GeForce 8200
System Bus
Up to 5200 MT/s ; HyperTransport⢠3.0 interface for AM3/AM2+ CPU
Memory
2 x DIMM, Max. 8 GB, DDR2 1066/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to AMD CPU limitation, DDR2 1066 is supported by AM2+/AM3 CPU for one DIMM per channel only.
*Refer to www.asus.com for the memory QVL (Qualified Vendors List)
Expansion Slots
1 x PCIe 2.0 x16
1 x PCIe x1
2 x PCI
VGA
Integrated NVIDIA GeForce Series DirectX10 graphics processor
Max. shared memory: 512 MB
Supports RGB with max. resolution up to 1920x1440 @75Hz
Support Hybrid SLI*
*Refer to the ASUS website at www.asus.com for details on how to use Hybrid SLI.
Storage
Southbridge
1 xUltraDMA 133/100 interface
4 xSATA 3 Gb/s ports Support RAID 0,1,0+1,5,JBOD
** Due to the Windows XP/ Vista limitation, the RAID array with the total capacity over 2TB cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk only.
LAN
Broadcom B5071 Phy Gigabit LAN
Audio
VIA VT 1708S 6 -Channel
- Support Multi-streaming ,Anti Pop Function,Single S/PDIF out port at back I/O
USB
10 USB 2.0 ports (6 ports on mid-board, 4 ports on back panel)
ASUS Unique Features
ASUS Quiet Thermal Solution:
- ASUS Q-Fan
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
Back Panel I/O Ports
1 x Parallel
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x LAN(RJ45) port
4 x USB 2.0/1.1
1 x COM port
6 -Channel Audio I/O
1 x RGB
Internal I/O Connectors
3 x USB connectors for 6 additional USB 2.0amp;1.1 ports
1 x IDE connector
4 x SATA connectors
1 x CPU Fan connector
1 x High Definition front panel audio connector
1 x CD audio-in connector
Internal Speaker Connecter
1 x F_Panel
1 x 4 pin, ATX + 12V, power connector
1 x 24pin, EPS 12V power connector
1 x 4pin,S/PDIF output connector
BIOS
8 Mb Flash ROM
AMI BIOS Pnp, DMI v2.0, Wfm2.0, ACPI v2.0A, SMBIOS V2.5
Accessories
User's manual
1 x I/O Shield
1 x UltraDMA 133/100/66 cable
1 x SATA cable
Support Disc
Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS Update
Form Factor
uATX Form Factor
9.6 inch x 8 inch ( 24.4 cm x 20.3 cm )
AMD AM3/AM2+/AM2 ;Phenomâ¢II /Athlonâ¢II /Phenom⢠/ Athlon⢠/Sempron⢠Processors
AMD Cool 'n' Quiet⢠Technology
CPU Power up to 95W
Chipset
NVIDIA GeForce 8200
System Bus
Up to 5200 MT/s ; HyperTransport⢠3.0 interface for AM3/AM2+ CPU
Memory
2 x DIMM, Max. 8 GB, DDR2 1066/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to AMD CPU limitation, DDR2 1066 is supported by AM2+/AM3 CPU for one DIMM per channel only.
*Refer to www.asus.com for the memory QVL (Qualified Vendors List)
Expansion Slots
1 x PCIe 2.0 x16
1 x PCIe x1
2 x PCI
VGA
Integrated NVIDIA GeForce Series DirectX10 graphics processor
Max. shared memory: 512 MB
Supports RGB with max. resolution up to 1920x1440 @75Hz
Support Hybrid SLI*
*Refer to the ASUS website at www.asus.com for details on how to use Hybrid SLI.
Storage
Southbridge
1 xUltraDMA 133/100 interface
4 xSATA 3 Gb/s ports Support RAID 0,1,0+1,5,JBOD
** Due to the Windows XP/ Vista limitation, the RAID array with the total capacity over 2TB cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk only.
LAN
Broadcom B5071 Phy Gigabit LAN
Audio
VIA VT 1708S 6 -Channel
- Support Multi-streaming ,Anti Pop Function,Single S/PDIF out port at back I/O
USB
10 USB 2.0 ports (6 ports on mid-board, 4 ports on back panel)
ASUS Unique Features
ASUS Quiet Thermal Solution:
- ASUS Q-Fan
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
Back Panel I/O Ports
1 x Parallel
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x LAN(RJ45) port
4 x USB 2.0/1.1
1 x COM port
6 -Channel Audio I/O
1 x RGB
Internal I/O Connectors
3 x USB connectors for 6 additional USB 2.0amp;1.1 ports
1 x IDE connector
4 x SATA connectors
1 x CPU Fan connector
1 x High Definition front panel audio connector
1 x CD audio-in connector
Internal Speaker Connecter
1 x F_Panel
1 x 4 pin, ATX + 12V, power connector
1 x 24pin, EPS 12V power connector
1 x 4pin,S/PDIF output connector
BIOS
8 Mb Flash ROM
AMI BIOS Pnp, DMI v2.0, Wfm2.0, ACPI v2.0A, SMBIOS V2.5
Accessories
User's manual
1 x I/O Shield
1 x UltraDMA 133/100/66 cable
1 x SATA cable
Support Disc
Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS Update
Form Factor
uATX Form Factor
9.6 inch x 8 inch ( 24.4 cm x 20.3 cm )
