- Intel® Atom™ processor N270 (1.60 GHz, 533 MHz FSB, 512 KB L2 cache)
- Mobile Intel® 945GSE Express Chipset (DDR2 400/533 MHz)
- Mobile Intel® 82801GBM Chipset
Operating System
- Windows XP® Home
Memory
- Single channel with onboard SDRAM and one soDIMM slot
• DDR2 533 MHz SDRAM memory interface design
• Onboard SDRAM: 512 MB
- soDIMM slot: Supports 512 MB/1 GB soDIMMs for total system memory of up to 1.5 GB5
Storage
- NAND flash module or hard disk drive for internal storage7
- NAND flash module: 8 GB
- Storage expansion: SD™ Card reader
- Multi-in-1 card reader: Supporting Secure Digital™ (SD) Card, MultiMediaCard (MMC), Reduced-Size Multimedia Card (RS-MMC), Memory Stick® (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
- Supporting storage cards with adapter: miniSD™, microSD™, Memory Stick Duo™, Memory Stick PRO Duo™
Display
- 8.9″ WSVGA high-brightness (typical 180-nit) Acer CrystalBrite™ TFT LCD, 1024 x 600 pixel resolution
• LED backlight
• 262,000 colors supported
Multimedia
- High-definition audio support
- Two built-in stereo speakers
- MS-Sound compatible
- Built-in digital microphone
Communication
- Integrated Acer Crystal Eye webcam, supporting 0.3 megapixel resolution
- WLAN2: Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology,
- LAN: 10/100 Mbps Fast Ethernet
- Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology2
I/O Interfaces
- Multi-in-1 card reader
- SD™ Card reader for storage expansion
- Three USB 2.0 ports
- External display (VGA) port
- Headphone/speaker/line-out jack
- Microphone-in jack
- Ethernet (RJ-45) port
- DC-in jack for AC adapter
Power supply and Battery
- 30 W adapter with power cord
- 24 W 2200 mAh 3-cell Li-ion battery pack
- 57 W 2600 mAh 6-cell Li-ion battery pack
- 3-hour battery life for SKUS with NAND flash module and 3-cell battery pack
- 7-hour battery life for SKUS with NAND flash module and 6-cell battery pack
Keyboard Special Controls
- 84-key keyboard with 1.6 mm (minimum) key travel
- Touchpad pointing device with two buttons
- 12 function keys, four cursor keys, one Windows® key for Windows® XP Home or one Home key for Linpus™
- Linux® Lite version, hotkey controls, embedded numeric keypad, international language support
- Power button with LED
- Easy-access switches with LED: WLAN, WWAN1
Weight and Dimensions
- 249 (W) x 170 (D) x 29 (H) mm (9.8 x 6.7 x 1.14 inches) for SKUs with NAND flash module and 3-cell battery pack
- 249 (W) x 195 (D) x 36 (H) mm (9.8 x 6.7 x 1.42 inches) for SKUs with hard disk drive and 6-cell battery pack
- 995 g (2.19 lbs.) for SKUs with NAND flash module and 3-cell battery pack
- 1.26 kg (2.78 lbs.) for SKUs with hard disk drive and 6-cell battery pack
