ASRock P4VM890 478 VIA P4M890 Micro ATX

CPU
- Socket 478 for Intel® Pentium® 4 / Celeron® D (Prescott, Northwood, Willamette) processors

- FSB 800/533/400 MHz

- Supports Hyper-Threading Technology

- Supports Untied Overclocking Technology
Chipset
- Northbridge: VIA® P4M890

- Southbridge: VIA® VT8237R Plus
Memory
- 2 x DDR DIMM slots

- Supports DDR400/333 non-ECC, un-buffered memory

- Max. capacity of system memory: 2GB
BIOS
- 4Mb AMI BIOS

- AMI Legal BIOS

- Supports "Plug and Play"

- ACPI 1.1 Compliance Wake Up Events

- Supports Jumperfree

- SMBIOS 2.3.1 Support
Audio, Video and Networking
Graphics
- Integrated VIA® UniChrome Pro 3D/2D Graphics

- DirectX 7.0 VGA

- Max. shared memory 64MB
Audio
- Realtek ALC653 5.1channel AC'97 audio codec
LAN
- VIA® PHY VT6103

- Speed: 10/100 Ethernet

- Supports Wake-On-LAN
Expansion / Connectivity
Slots
- 3 x PCI slots

- 1 x PCI Express x16 slot

- 1 x AMR slot
Connector
- 2 x SATA 1.5 Gb/s connectors, support RAID (RAID 0, RAID 1, and JBOD) and Hot Plug functions

- 2 x ATA133 IDE connectors (support 4 x IDE devices)

- 1 x Floppy connector

- 1 x IR header

- 1 x COM header

- CPU/Chassis FAN connector

- 20 pin ATX power connector

- 4 pin 12V power connector

- CD in header

- AUX in header

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports; 2 of them are shared with USB45 ports on the I/O panel)
Rear Panel I/O
ASRock I/O Plus

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x VGA Port

- 1 x Parallel Port (ECP/EPP Support)

- 6 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port

- Audio Jack: Line in / Front Speaker / Microphone
Other Features / Miscellaneous
Hybrid Booster
- CPU Frequency Stepless Control

- ASRock U-COP

- Boot Failure Guard (B.F.G.)
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
Accessories
- Quick Installation Guide, Support CD, I/O Shield

- Floppy/ATA 133 Cables

- 1 x SATA Data Cable (optional)

- 1 x SATA 1 to 1 Power Cable (optional)

- 1 x COM Port Bracket
Hardware Monitor
- CPU Temperature Sensing

- Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
Form Factor
- Micro ATX Form Factor: 9.6-in x 8.0-in, 24.4 cm x 20.3 cm
OS
- Microsoft® Windows® 2000 / XP compliant
Certifications
- FCC, CE, WHQL
