ASUS A7N8X-E Deluxe

CPU
Socket A for AMD Athlon XP/Athlon / Duron

Thoroughbred/ Barton Core Support
Chipset
NVIDIA nForce2 Ultra 400

NVIDIA nForce2 MCP-T
Front Side Bus
400/333/266/200 MHz
Memory
- 3 x 184-pin DIMM Sockets support max. 3GB PC3200/PC2700/PC2100/PC1600 non-ECC DDR SDRAM memory

- Dual Channel Memory Architecture
Expansion Slots
1 x AGP Pro/8X (1.5V only)

5 x PCI

1 x ASUS Wi-Fi slot for optional wireless LAN upgrade
Storage/RAID
NVIDIA nForce2 MCP-T

-2 x UltraDMA 133/100/66/33

Silicon Image Sil 3112A RAID Controller:

-2 x Serial ATA

-RAID 0, RAID1
Audio
Realtek ALC650 6-Channel CODEC

Integrated APU(Audio Processor Unit)

Dolby Digital (AC-3) Encorder

S/PDIF in / out interface
LAN
2 Ports

-Marvell 88E8001 Gigabit Lan PCI Controller supporting 10/100/1000 BASE-T Ethernet

-MCP-T integrated NVIDIA MAC + Realtek 8201BL PHY
IEEE 1394
Realtek PHY 8801B with Two 1394 Ports
USB
Integrated 6 USB2.0 ports
Special Features
Power Loss Restart

Support S/PDIF in / out interface

ASUS POST Reporter

ASUS C.O.P. (CPU Overheating Protection)

ASUS Q-Fan technology
Overclocking Features
ASUS JumperFree

CPU, Memory, and AGP voltage adjustable

SFS (Stepless Frequency Selection) from 100MHz up to 300MHz

Adjustable FSB/DDR ratio, Fixed AGP/PCI frequencies
Internal I/O Connectors
- 1 x USB 2.0 connector supports additional 2 USB 2.0 ports

- CPU / Chassis / Power FAN connectors

- 20-pin ATX Power connector

- IDE LED connector, power LED connector

- Chassis Intrusion, SIR

- S/PDIF in / out connector

- CD / AUX / Modem audio in

- 2 x IEEE1394 ports connector

- GAME/MIDI connector

- 2 x SATA ports

- COM2 connector

- Front panel audio connector
Back Panel I/O Ports
1 x Parallel

1 x Serial

1 x PS/2 Keyboard

1 x PS/2 Mouse

1 x Audio I/O

2 x RJ45

1 x S/PDIF out+1 x Surround L/R audio jack+ 1 x CNTR/LFE audio jack

4 x USB 2.0/1.1
BIOS
4 Mb Flash ROM, Award BIOS, PnP, DMI2.0
Industrial Standard
PCI 2.2, USB 2.0
Manageability
WfM 2.0,DMI 2.0,WOL by PME,WOR by PME, Chassis Intrusion
Support Disc
- Drivers

- ASUS PC Probe

- Trend Micro PC-cillin 2002 anti-virus software (OEM version)

- ASUS LiveUpdate Utility
Accessories
InterVideo WinDVD Suite

User's manual

UltraDMA cable

IDE cable

FDD cable

2-port USB2.0

I/O shield

Serial ATA Power Cable

Serial ATA cables

2 port IEEE1394 cables
Form Factor
ATX Form Factor, 12"x 9.6"(30.5cm x 24.5cm)
