Popis
CPU
Supports AMD Athlon64™/ Sempron™ Socket 754 processor
Chipset
Northbridge: VIA K8T800
Southbridge: VIA VT8237R+
Super I/O: ITE IT8705
Integrated peripherals
Realtek 8100C Ethernet LAN controller
Realtek ALC850 AC'97 Audio Codec
Memory
Type: DDR400/ 333/ 266- 184pin
Max capacity: Up to 3GB by 3 DIMM slots
Internal I/O Connectors
2 x Serial ATA connector
2 x UDMA ATA 133/100/66 IDE connector
1 x FDD connector
2 x USB 2.0/1.1 connector (supports 4 ports via cable)
CD-in connector, Front Audio pin-header, S/PDIF in/out pin-header, IR pin-header
2 x cooling fan pin-header
Expansion Slots
1 x AGP 8x/4x slot (AGP 3.0 compliant).
5 x PCI slots (PCI 2.2 compliant)
Back Panel Connectors
PS/2 Keyboard / Mouse port
2 x COM port
1 x LPT port
4 x USB 2.0/1.1 port
1 x RJ45 LAN port
Audio port (1 x Line-in / 1 x Line-out / 1 x Mic)
Power
ATX power connector and ATX 12V connector
Power-off by Windows 98/ Me/ 2000/ XP shut down and switch
Form Factor
ATX form factor
29.5 x 21.5 cm
H/W Monitoring
System health status auto-detect and report by BIOS
Hardware detecting and reporting for case open, CPU voltage, and fan speed
BIOS
2Mb flash ROM, Phoenix BIOS
Use of licensed AwardTM BIOS
Other Features
Xpress™ Installation,
Xpress™ Recovery
Xpress™ BIOS rescue
Q-Flash™
@BIOS™
Unique Features
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
This product does not support Win9X/ME, due to most hardware/software vendors no longer offer support for Win9X/ME. However we still offer available related drivers to serve our customers.
Supports AMD Athlon64™/ Sempron™ Socket 754 processor
Chipset
Northbridge: VIA K8T800
Southbridge: VIA VT8237R+
Super I/O: ITE IT8705
Integrated peripherals
Realtek 8100C Ethernet LAN controller
Realtek ALC850 AC'97 Audio Codec
Memory
Type: DDR400/ 333/ 266- 184pin
Max capacity: Up to 3GB by 3 DIMM slots
Internal I/O Connectors
2 x Serial ATA connector
2 x UDMA ATA 133/100/66 IDE connector
1 x FDD connector
2 x USB 2.0/1.1 connector (supports 4 ports via cable)
CD-in connector, Front Audio pin-header, S/PDIF in/out pin-header, IR pin-header
2 x cooling fan pin-header
Expansion Slots
1 x AGP 8x/4x slot (AGP 3.0 compliant).
5 x PCI slots (PCI 2.2 compliant)
Back Panel Connectors
PS/2 Keyboard / Mouse port
2 x COM port
1 x LPT port
4 x USB 2.0/1.1 port
1 x RJ45 LAN port
Audio port (1 x Line-in / 1 x Line-out / 1 x Mic)
Power
ATX power connector and ATX 12V connector
Power-off by Windows 98/ Me/ 2000/ XP shut down and switch
Form Factor
ATX form factor
29.5 x 21.5 cm
H/W Monitoring
System health status auto-detect and report by BIOS
Hardware detecting and reporting for case open, CPU voltage, and fan speed
BIOS
2Mb flash ROM, Phoenix BIOS
Use of licensed AwardTM BIOS
Other Features
Xpress™ Installation,
Xpress™ Recovery
Xpress™ BIOS rescue
Q-Flash™
@BIOS™
Unique Features
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
This product does not support Win9X/ME, due to most hardware/software vendors no longer offer support for Win9X/ME. However we still offer available related drivers to serve our customers.
