Popis
System
CPU: VVTK-1000 SoC
Flash: 4MB
RAM: 32MBMB
Embedded OS: Linux 2.4
Lens
f=4.0 mm
F 2.0
Board lens
Fixed
Shutter Time
1/60 ~ 1/15,000 sec
Minimum Illumination
1.5 Lux / F2.0 ( typical )
Video
Compression: MPEG-4
Streaming:
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
Supports 3GPP mobile surveillance
Frame rates:
MPEG-4: Up to 30/25 fps at 640x480
Image Settings
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip amp; mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGC AWB AES
Audio
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
Interface:
Built-in microphone
Supports audio mute
Networking
10/100 Mbps Ethernet, RJ-45
Built-in 802.11b/g WLAN
Protocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS
Alarm and Event Management
Triple-window video motion detection
Event notification using HTTP, SMTP, or FTP
Security
Multi-level user access with password protection
IP address filtering
Users
10 clients on-line monitoring at the same time
Dimensions
Depth: 34.8mm
Width: 105.7mm
Height: 77.2mm
Weight
Net: 16 g
LED Indicator
System power and status indicator
System activity and network link indicator
Power
5V DC
Power consumption: Max. 3. W
Approvals
CE FCC
Operating Environments
Temperature: 0 ~ 50 °C (32 ~ 122 °F)
Humidity: 20% ~ 80%
Viewing System Requirements
OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above
Installation, Management, and Maintenance
Installation Wizard 2
32-CH central management software
Supports firmware upgrade
Applications
SDK available for application development and system integration
Warranty
12 months
CPU: VVTK-1000 SoC
Flash: 4MB
RAM: 32MBMB
Embedded OS: Linux 2.4
Lens
f=4.0 mm
F 2.0
Board lens
Fixed
Shutter Time
1/60 ~ 1/15,000 sec
Minimum Illumination
1.5 Lux / F2.0 ( typical )
Video
Compression: MPEG-4
Streaming:
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
Supports 3GPP mobile surveillance
Frame rates:
MPEG-4: Up to 30/25 fps at 640x480
Image Settings
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip amp; mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
AGC AWB AES
Audio
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
Interface:
Built-in microphone
Supports audio mute
Networking
10/100 Mbps Ethernet, RJ-45
Built-in 802.11b/g WLAN
Protocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS
Alarm and Event Management
Triple-window video motion detection
Event notification using HTTP, SMTP, or FTP
Security
Multi-level user access with password protection
IP address filtering
Users
10 clients on-line monitoring at the same time
Dimensions
Depth: 34.8mm
Width: 105.7mm
Height: 77.2mm
Weight
Net: 16 g
LED Indicator
System power and status indicator
System activity and network link indicator
Power
5V DC
Power consumption: Max. 3. W
Approvals
CE FCC
Operating Environments
Temperature: 0 ~ 50 °C (32 ~ 122 °F)
Humidity: 20% ~ 80%
Viewing System Requirements
OS: Microsoft Windows 2000/XP/Vista/7
Browser: Mozilla Firefox, Internet Explorer 6.x or above
Cell phone: 3GPP player
Real Player: 10.5 or above
Quick Time: 6.5 or above
Installation, Management, and Maintenance
Installation Wizard 2
32-CH central management software
Supports firmware upgrade
Applications
SDK available for application development and system integration
Warranty
12 months
