Screen dimensions
Screen type
Active matrix - TFT LCD
Screen dimensions
17 inches (17-inch viewable image size)
Preset display area:
Horizontal
337.92 ± 3 mm (13.3 inches ± 0.12 inches)
Vertical
270.34 ± 3 mm (10.6 inches ± 0.12 inches)
Pixel pitch
0.264 mm
Viewing angle
+/- 85° (vertical) typical
+/- 85° (horizontal) typical
Luminance output
250 CD/m² typical, 200 CD/m² minimum
Contrast ratio
500 to 1 typical, 400 to 1 minimum
Faceplate coating
Antiglare with hard-coating 3H
Backlight
CCFT (4) edgelight system
Resolution
Horizontal scan range
31 kHz to 80 kHz (automatic)
Vertical scan range
56 Hz to 76 Hz (automatic)
Optimal preset resolution
1280 x 1024 at 60 Hz
Highest preset resolution
1280 x 1024 at 75 Hz
* Highest addressable resolution
1600 x 1200 at 60 Hz (UXGA)
* Addressable means the monitor will sync up to this mode.
However, Dell does not guarantee the image will be sized, shaped and centered correctly.
* Dell does not officially support the UXGA video mode. Video performance could be impaired in this mode. The following message will appear when in this mode "Cannot Display This Video mode". In the event the system is in UXGA mode, the user will still be able to view the screen in order to change the resolution to optimal.
Dell guarantees image size and centering for all preset modes listed in the following table.
Preset Display Modes
Display Mode
Horizontal Frequency (kHz)
Vertical Frequency (Hz)
Pixel Clock (MHz)
Sync Polarity (Horizontal/Vertical)
IBM®, VGA2, 720 x 400
31.469
70.087
28.3
-/+
IBM, VGA3, 640 x 480
31.469
59.940
25.2
-/-
VESA®, 640 x 480
37.500
75.000
31.5
-/-
VESA, 800 x 600
37.879
60.317
49.5
+/+
VESA, 800 x 600
46.875
75.000
49.5
+/+
VESA, 1024 x 768
48.363
60.004
65.0
-/-
VESA, 1024 x 768
60.023
75.029
78.8
+/+
VESA, 1152 x 864
67.500
75.000
108
+/+
VESA, 1280 x 1024
64.000
60.000
135.0
+/+
VESA, 1280 x 1024
79.976
75.025
135.0
+/+
Electrical
Video input signals
Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50 ohm input impedance
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level
AC input voltage / frequency / current
90 to 264 VAC / 50 or 60 Hz + 3 Hz /
1.5 A (RMS) at 120 VAC and
0.8 A (RMS) at 220 VAC
Panel DC input
14 VDC at 3V
Physical Characteristics
Connector type
15-pin D-subminiature, blue connector; DVI-D, white connector
Signal cable type
Analog: Detachable, D-sub, 15pin, attached to the monitor
Digital: Detachable, DVI-D, Solid pins, Digital signal cable detached to the monitor and included in a separate plastic bag
Dimensions:
Height
458.5 mm (18.1 inches)
Width
440 mm (17.3 inches)
Depth
220 mm (8.7 inches)
Weight (monitor, cables, and brick)
7.45 Kg (16.4 lb)
Weight (with packaging)
10.1 Kg (22.3 lb)
Environmental
Temperature:
Operating
5° to 35°C (41° to 95°F)
Nonoperating
Storage: 0° to 60°C (32° to 140°F)
Shipping: -20° to 60°C(-4° to 140°F)
Humidity:
Operating
10% to 80% (noncondensing)
Nonoperating
Storage: 5% to 90% (noncondensing)
Shipping: 5% to 95%(noncondensing)
Altitude:
Operating
3,658 m (12,000 ft)
Nonoperating
12,192 m (40,000 ft)
Thermal dissipation
136.52 BTU/hour (maximum)
116.04 BTU/hour (typical)
Power Management Modes
If you have VESA's DPMS compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. This is referred to as 'Power Save Mode'* (any one of the 'standby', 'suspend' or 'active-off' modes). If input from keyboard, mouse or other input devices is detected by the computer, the monitor will automatically "wake up". The following table shows the power consumption and signaling of this automatic power saving feature:
VESA Modes
Horizontal Sync
Vertical Sync
Video
Power Indicator
Power Consumption
Normal operation
Active
Active
Active
Green
40 W (maximum);
34 W (typical)
Standby mode
Inactive
Active
Blanked
Amber
Less than 5 W
Suspend mode
Active
Inactive
Blanked
Amber
Less than 5 W
Active-off mode
Inactive
Inactive
Blanked
Amber
Less than 5 W
