CPU
Supports AMD-K7 Athlon / Athlon XP Socket A 200/266/333 MHz FSB Processors
Supports AMD-K7 Duron Socket A 200 MHz FSB Processors
Chipset
VIA KT400/VT8235 chipset
Supports Hi-Speed Universal Serial Bus (USB 2.0)
Supports Advanced Configuration and Power Management Interface (ACPI)
Accelerated Graphics Port connector supports AGP 4X/8X (1.5V/0.8V)
Memory
Four 184-pin DIMM sockets
Supports 2 DIMM DDR 333/400 (Max. 2GB)
Supports 3 DIMM Un-buffered DDR 200/266 (Max. 3GB)
Supports 4 DIMM Registered DDR 200/266 (Max. 3.5GB)
Audio
6-Channel AC 97 CODEC on board
Professional digital audio interface supports 24-bit S/PDIF Out
LAN
On board 10/100Mb Operation supports ACPI amp; Wake on LAN
System BIOS
SoftMenuTM Technology to set CPU parameters
Supports Plug-and-Play (PNP)
Supports Advanced Configuration Power Interface (ACPI)
Supports Desktop Management Interface (DMI)
Write-Protect Anti-Virus function by AWARD BIOS
Internal I/O Connectors
1 x AGP, 6 x PCI slots
Floppy Port supports up to 2.88MB
2 x Ultra DMA 33/66/100/133 Connectors
2 x USB headers
1 x CD-IN, 1 x AUX-IN
1 x IrDA
Back Panel I/O
1 x PS/2 Keyboard, 1 x PS/2 mouse
2 x Serial, 1 x Parallel
1 x S/PDIF Output
Audio connectors (Front Speaker, Line-
