Popis
2x Intel Xeon 3.00 GHz processor / 512 KB cache (with 400 MHz system bus)
512 KB level 2 cache per processor
Server Chipset
Enterprise Class chipset: ServerWorks GC HE 1
Memory
Standard 3GB ( 6 x 512 MB) PC1600-MHz Registered ECC SDRAM
Network Controller
Embedded HP NC3163 Fast Ethernet NIC PCI 10/100 with full WOL (Wake On LAN) and PXE support + LAN Ethernet 1000
Expansion Slots
7 - PCI-X Slots
4 - 64-bit / 100 MHz (Hot Plug)
3 - 64-bit / 100 MHz (Non-Hot Plug)
z toho su 2 fyzicky obsadene PCI-X scsi radicmi
Storage Controllers
Integrated Dual Channel Wide Ultra3 SCSI Adapter
Storage
1.44 MB Diskette Drive
40x IDE CD-ROM Drive
Hard Drives: None
Internal Storage: 12 - 1 inch hot plug hard drive bays standard (2 individual 6 bay cages, each requiring it's own SCSI channel)
1.019 TB Maximum storage with optional ML5xx G2 Internal Two Bay Hot Plug Wide Ultra2/Ultra3 SCSI Drive Cage with Fan. (12 x 72.8 GB 1 inch + 2 x 72.8 GB 1 inch)
Half Height Bays 2 bays for optional tape backup, DVD, or SCSI devices
Interfaces
Parallel - 1
Serial - 2
Pointing Device (Mouse) - 1
Graphics - 1
Keyboard - 1
Network RJ-45 - 1
USB - 2 2
External SCSI - 1
Graphics
Integrated Rage XL Video Controller with 8 MB SDRAM Video Memory
Form Factor
7U Tower or Rack models available.
Industry Standard Compliance
ACPI 1.0 Compliant PCI 2. 2 Compliant
PCI-X 1.0 Compliant
WOL Support
Microsoft Windows Logo certifications
Novell certified
Manageability
Insight Manager 7
Redundant ROM
Remote Flash ROM Utility
HP Remote Lights-Out Edition (optional)
Automatic Server Recovery-2 (ASR-2)
Integrated Management Log
Server Health Logging
Drive Parameter Tracking (with Smart Array Controller)
Dynamic Sector Repairing (with Smart Array Controller)
Pre-Failure Warranty (covers processors, hard drives and memory)
Security
Power-on password
Hot plug keyboard password
Diskette drive control
Diskette boot control
QuickLock, Network Server Mode
Parallel and serial interface control
Administrator's password
Disk configuration lock
Power Supply
2x 600W Hot Plug Power Supply standard
Fans
Hot Plug Power System Fans standard
Optional redundant Hot Plug Fans 5
512 KB level 2 cache per processor
Server Chipset
Enterprise Class chipset: ServerWorks GC HE 1
Memory
Standard 3GB ( 6 x 512 MB) PC1600-MHz Registered ECC SDRAM
Network Controller
Embedded HP NC3163 Fast Ethernet NIC PCI 10/100 with full WOL (Wake On LAN) and PXE support + LAN Ethernet 1000
Expansion Slots
7 - PCI-X Slots
4 - 64-bit / 100 MHz (Hot Plug)
3 - 64-bit / 100 MHz (Non-Hot Plug)
z toho su 2 fyzicky obsadene PCI-X scsi radicmi
Storage Controllers
Integrated Dual Channel Wide Ultra3 SCSI Adapter
Storage
1.44 MB Diskette Drive
40x IDE CD-ROM Drive
Hard Drives: None
Internal Storage: 12 - 1 inch hot plug hard drive bays standard (2 individual 6 bay cages, each requiring it's own SCSI channel)
1.019 TB Maximum storage with optional ML5xx G2 Internal Two Bay Hot Plug Wide Ultra2/Ultra3 SCSI Drive Cage with Fan. (12 x 72.8 GB 1 inch + 2 x 72.8 GB 1 inch)
Half Height Bays 2 bays for optional tape backup, DVD, or SCSI devices
Interfaces
Parallel - 1
Serial - 2
Pointing Device (Mouse) - 1
Graphics - 1
Keyboard - 1
Network RJ-45 - 1
USB - 2 2
External SCSI - 1
Graphics
Integrated Rage XL Video Controller with 8 MB SDRAM Video Memory
Form Factor
7U Tower or Rack models available.
Industry Standard Compliance
ACPI 1.0 Compliant PCI 2. 2 Compliant
PCI-X 1.0 Compliant
WOL Support
Microsoft Windows Logo certifications
Novell certified
Manageability
Insight Manager 7
Redundant ROM
Remote Flash ROM Utility
HP Remote Lights-Out Edition (optional)
Automatic Server Recovery-2 (ASR-2)
Integrated Management Log
Server Health Logging
Drive Parameter Tracking (with Smart Array Controller)
Dynamic Sector Repairing (with Smart Array Controller)
Pre-Failure Warranty (covers processors, hard drives and memory)
Security
Power-on password
Hot plug keyboard password
Diskette drive control
Diskette boot control
QuickLock, Network Server Mode
Parallel and serial interface control
Administrator's password
Disk configuration lock
Power Supply
2x 600W Hot Plug Power Supply standard
Fans
Hot Plug Power System Fans standard
Optional redundant Hot Plug Fans 5
