Specifications
Features amp; Benefits
Built-in 4 ports Fast Ethernet switch: 10/100Mbps MDI/MDIX auto-sensing.
One 10/100Mps WAN RJ45 port to connect with DSL/Cable modem for broadband Internet access.
DHCP server to automatically assign and manage LAN IP addresses
Built-in NAT function: allow multiple PCs and devices to share one Internet connection.
Over 90Mbps routing speed via wired network
Web-based user interface for easy-to-use configuration and management via Internet brower communication.
Built-in firewall to keep you from malicous softwares and viruses
Provide 64/128bit WEP and WPA wireless security ecryption technologies to protect your wireless communication.
VPN support: pass through of PPTP, L2TP, and IPSec.
Easy to upgrade: firmware upgrade can be operated via web-basde UI and MSI upgrade software
High speed for wireless LAN connection: support both IEEE 802.11b and 802.11g. Up to 54 Mbps data rate in 802.11g network
Seamless roaming between the IEEE 802.11b and 802.11g WLAN infrastructure
Support auto fallback data rate: 6/12/18/24/36/48/54 Mbps in 802.11g mode; 1/2/5.5/11Mbps in 802.11b mode
Hardware and Port Characteristic
LAN Port
4 x RJ45, 10/100 Mbps with Auto-MDI/MDIX
WAN Port
1 x RJ45, 10/100 Mbps with Auto-MDI/MDIX
Input Power
AC 12V1A
Wireless Support
Solution
Ralink 802.11g on Board
Standard
IEEE 802.11b / 802.11g
Data Rate*
6/12/18/24/36/48/54Mbps in 802.11g mode
1/2/5.5/11Mbps in 802.11b mode
Operating Frequency
2.4GHz
Range Coverage
Per cell indoors approx. 35-100 meters
Per cell outdoors up to 100-300 meters
Antenna
2 dBi dipole antenna x 1
Antenna Connector
R-SMA female x 1
Number of Channels
America/ FCC: 2.412~2.462GHz (11 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Security
WEP encryption and WPA supported
Environment, Certification and Reliability
Operating Temperature
Temperature: 0~40oC, Humidity 10%~90%
non-condensing
Storage Temperature
Temperature: -20~70oC, Humidity: 0~95%
non-condensing
EMC/Safety
FCC, CE, DGT
Reliability
Stress Test; Vibration Test; Drop Test
Operational amp; Functional Characteristic
Firmware Platform
MSI Proprietary Kernel
Management Method
Web-based
Supported WAN Type
Static IP Address
Dynamic IP Address (DHCP Client)
PPP over Ethernet
Multi-session PPP over Ethernet (For Japan only)
PPTP
L2TP
Connection Scheme
Connect on Demand / Auto-Disconnect
Manually Connect/Disconnect
Auto Reconnect
NAT Functionality
One-to-Many NAT
One-to-One NAT
Virtual Server
Special Application
DMZ Host
Access Control
MAC-level Access Control
Inbound/Outbound IP Filter
Domain Access Control
Firewall
NAT Firewall with SPI mode
DoS Detection
Event Logging
On-web logging
Syslog supported
Email Alert
VPN Supporting
IPSec, PPTP, LT2P Pass-Through
Routing
Static Route
Upgrade Method
Web-based
Windows Application
Other Features
DDNS Supported
UPnP Supported
SNMP Supported
Features amp; Benefits
Built-in 4 ports Fast Ethernet switch: 10/100Mbps MDI/MDIX auto-sensing.
One 10/100Mps WAN RJ45 port to connect with DSL/Cable modem for broadband Internet access.
DHCP server to automatically assign and manage LAN IP addresses
Built-in NAT function: allow multiple PCs and devices to share one Internet connection.
Over 90Mbps routing speed via wired network
Web-based user interface for easy-to-use configuration and management via Internet brower communication.
Built-in firewall to keep you from malicous softwares and viruses
Provide 64/128bit WEP and WPA wireless security ecryption technologies to protect your wireless communication.
VPN support: pass through of PPTP, L2TP, and IPSec.
Easy to upgrade: firmware upgrade can be operated via web-basde UI and MSI upgrade software
High speed for wireless LAN connection: support both IEEE 802.11b and 802.11g. Up to 54 Mbps data rate in 802.11g network
Seamless roaming between the IEEE 802.11b and 802.11g WLAN infrastructure
Support auto fallback data rate: 6/12/18/24/36/48/54 Mbps in 802.11g mode; 1/2/5.5/11Mbps in 802.11b mode
Hardware and Port Characteristic
LAN Port
4 x RJ45, 10/100 Mbps with Auto-MDI/MDIX
WAN Port
1 x RJ45, 10/100 Mbps with Auto-MDI/MDIX
Input Power
AC 12V1A
Wireless Support
Solution
Ralink 802.11g on Board
Standard
IEEE 802.11b / 802.11g
Data Rate*
6/12/18/24/36/48/54Mbps in 802.11g mode
1/2/5.5/11Mbps in 802.11b mode
Operating Frequency
2.4GHz
Range Coverage
Per cell indoors approx. 35-100 meters
Per cell outdoors up to 100-300 meters
Antenna
2 dBi dipole antenna x 1
Antenna Connector
R-SMA female x 1
Number of Channels
America/ FCC: 2.412~2.462GHz (11 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Security
WEP encryption and WPA supported
Environment, Certification and Reliability
Operating Temperature
Temperature: 0~40oC, Humidity 10%~90%
non-condensing
Storage Temperature
Temperature: -20~70oC, Humidity: 0~95%
non-condensing
EMC/Safety
FCC, CE, DGT
Reliability
Stress Test; Vibration Test; Drop Test
Operational amp; Functional Characteristic
Firmware Platform
MSI Proprietary Kernel
Management Method
Web-based
Supported WAN Type
Static IP Address
Dynamic IP Address (DHCP Client)
PPP over Ethernet
Multi-session PPP over Ethernet (For Japan only)
PPTP
L2TP
Connection Scheme
Connect on Demand / Auto-Disconnect
Manually Connect/Disconnect
Auto Reconnect
NAT Functionality
One-to-Many NAT
One-to-One NAT
Virtual Server
Special Application
DMZ Host
Access Control
MAC-level Access Control
Inbound/Outbound IP Filter
Domain Access Control
Firewall
NAT Firewall with SPI mode
DoS Detection
Event Logging
On-web logging
Syslog supported
Email Alert
VPN Supporting
IPSec, PPTP, LT2P Pass-Through
Routing
Static Route
Upgrade Method
Web-based
Windows Application
Other Features
DDNS Supported
UPnP Supported
SNMP Supported
