CPU
Supports Intel Pentium 4 Socket 478 processors with 400/533 MHz Front Side Bus
Chipset
Intel 845E / ICH4
Supports Ultra DMA 33/66/100
Accelerated Graphics Port connector supports AGP 4X Interface (1.5V only)
Memory
Three 184-pin DIMM sockets (unbuffered Non-ECC DIMM)
Supports 3 DIMM DDR 200/266 (Max. 2GB)
Serial ATA
On board 2-Channel Serial ATA interface of 1.5 G bps
ATA133 RAID
High Point HPT374 IDE RAID controller
Media XP (Optional)
Supports card reader function for Memory Stickâ¢, Secure Digital⢠and Type I/II CompactFlashâ¢
Supports Wireless Remote Control and S/PDIF Out / Mic In / Headphone Out / USB 2.0 / IEEE 1394
Audio
6-Channel AC 97 CODEC on board
USB 2.0
10 Ports USB 2.0
IEEE 1394
3 Ports IEEE 1394
LAN
On board RTL8100B 10/100M PCI Fast Ethernet Controller
System BIOS
SoftMenu⢠Technology to set CPU parameters
Supports Plug-and-Play (PNP)
Supports Advanced Configuration Power Interface (ACPI)
Internal I/O Connectors
1 AGP slot, 4 PCI slots
Floppy Port supports up to 2.88MB
2 x Ultra DMA 33/66/100 Connectors
2 x Ultra DMA 33/66/100/133 Connectors (RAID)
2 x Serial ATA 1.5G bps Connectors
1 x 6 Channel audio FPIO pin header (for Media XP)
2 x USB headers, 1 x IEEE 1394 header
2 x CD-IN, 1 x IrDA
Back Panel I/O
1 x PS/2 Keyboard, 1 x PS/2 mouse
4 x USB connectors
2 x IEEE 1394 connectors
1 x SPDIF Out connector
Audio connectors (Center/Sub, Surround Speaker)
Audio connectors (Front Speaker, Line-in, Mic-in)
2 x USB, 1 x RJ-45 LAN Connector
Miscellaneous
ATX form factor
Hardware monitoring - Including Fan speeds, Voltages, CPU and System environment temperature
Supports Wake Up by LAN, Modem Ring, RTC Alarm
Supports Keyboard and Mouse Power On
Supports STR (Suspend to RAM)
