LGA755 Socket for Intel® Core⢠2 Duo/ Pentium® Dual-Core/ Pentium® D/ Pentium® 4/ Celeron® D Processors with 1333*/1066/800/533 MHz FSB
*(FSB1333 CCPU will operate in over-clocking mode. Under this situation, PCIE frequency will also be over-clocked to 115MHz.)
Supports Intel® Hyper-Threading Technology
Chipset
Intel® 945GC/ Intel® ICH7 Chipset
Memory
2 x 240-pin DIMM sockets support max. memory capacity 4GB*
*(Due to the chipset limitation, the actual memory size may be less than 4GB for the reservation of system usage under Windows® XP and Windows® Vistaâ¢)
Supports Dual channel DDR2 667/ 533*/ 400 Un-buffered Non-ECC memory
*(Due to the chipsetsâ limitation, when using FSB1333 CPU, the DDR2 533 memory module will run at 500MHz.)
Graphics
Integrated Intel Graphics Media Accelerator 950
LAN
On board GbE LAN
Audio
On board HD 5.1CH Audio CODEC
Expansion Slots
1 x PCI-E X16, 1 x PCI-E X1, 2 x PCI
Internal I/O
1 x Floppy Port supports up to 2.88 MB
1 x Ultra DMA 100/66/33 IDE connector
4 x SATA 3Gb/s connector
2 x USB header (support 4 ports)
1 x FP-Audio, 1 x CD-In
Back Panel I/O
1 x PS/2 Keyboard, 1 x PS/2 Mouse
1 x Serial Port, 1 x Parallel Port, 1 x VGA Port
5.1 CH Audio connector (Line-in, Line-out, MIC-in)
4 x USB 2.0, 1 x RJ-45 LAN connector
Serial ATA
4 x SATA 3Gb/s through Intel® ICH7
Form Factor
Micro ATX form factor 244 x 220mm
PCB Color: Orange
RoHS
100% lead-free process and RoHS Compliant
