Popis
Display Type LCD display / TFT active matrix
Built-in Devices Microphone , Stereo speakers
Width 16.5 in
Depth 8.2 in
Height 17.5 in
Weight 13.2 lbs
Enclosure Color Gray
Localization English / United States
Display
Diagonal Size 17.0 in
Viewable Size 17.0 in
Dot Pitch / Pixel Pitch 0.26 mm
Max Resolution 1280 x 1024 / 75.0 Hz
Color Support 16.7 million colors
Max Sync Rate (V x H) 75.0 Hz x 80.0 KHz
Response Time 45.0 ms
Factory Preset Resolution Modes 1280 x 1024 / 75.0 Hz , 1280 x 1024 / 60.0 Hz
Front Panel Controls Power on/off , Brightness , Select , Menu
On-Screen Controls H/V-position , Brightness , Contrast , Auto-configuration , Color adjustment , Clock , Phase , H/V-size , Recall settings , Input select , Language select
OSD Languages Italian , English , Spanish , French , German
Display Screen Coating Anti-static , Anti-glare
Image Aspect Ratio 5:4
Image Brightness 250.0 cd/m2
Image Contrast Ratio 300:1
Image Max H-View Angle +60 / -60
Image Max V-View Angle +40 / -65
Video Input
Analog Video Format None
Analog Video Signal RGB
Digital Video Standard Digital Visual Interface (DVI)
Audio Output
Type speaker(s) - Stereo - Integrated
Output Power / Channel 8.0 Watt
Input Device
Type None
Expansion / Connectivity
Interfaces 1.0 x Headphones - Output - Mini-phone stereo 3.5 mm - 1.0
Connections 1.0 x Display / video - Line-out - Mini-phone mono 3.5 mm - 1.0 , 1.0 x Audio - VGA - 24 pin digital DVI - 1.0 , 1.0 x Microphone - VGA - Mini-phone stereo 3.5 mm - 1.0 , 1.0 x Display / video - Input - 15 pin HD D-Sub (HD-15) - 1.0
Miscellaneous
Cables Included 1.0 x Microphone cable , 1.0 x Audio cable
Features Kensington MicroSaver security system
Compliant Standards FEMKO , ICES-003 , DDC-2B , NEMKO , DEMKO , CSA , PTB , C-Tick , UL 1950 , TCO '99 , TUV GS , EPA Energy Star , FCC Class B certified , SEMKO , VCCI Class B ITE , IEC950 , Plug and Play , DDC-1 , NOM
Power
Form Factor Internal
Voltage Required AC 120 V
Power Consumption Operational 45.0 Watt
Power Consumption Stand by / Sleep 2.3 Watt
Software / System Requirements
Software type Drivers amp; Utilities
Min Operating system None
Environmental Parameters
Operating humidity range 20 - 80%
Built-in Devices Microphone , Stereo speakers
Width 16.5 in
Depth 8.2 in
Height 17.5 in
Weight 13.2 lbs
Enclosure Color Gray
Localization English / United States
Display
Diagonal Size 17.0 in
Viewable Size 17.0 in
Dot Pitch / Pixel Pitch 0.26 mm
Max Resolution 1280 x 1024 / 75.0 Hz
Color Support 16.7 million colors
Max Sync Rate (V x H) 75.0 Hz x 80.0 KHz
Response Time 45.0 ms
Factory Preset Resolution Modes 1280 x 1024 / 75.0 Hz , 1280 x 1024 / 60.0 Hz
Front Panel Controls Power on/off , Brightness , Select , Menu
On-Screen Controls H/V-position , Brightness , Contrast , Auto-configuration , Color adjustment , Clock , Phase , H/V-size , Recall settings , Input select , Language select
OSD Languages Italian , English , Spanish , French , German
Display Screen Coating Anti-static , Anti-glare
Image Aspect Ratio 5:4
Image Brightness 250.0 cd/m2
Image Contrast Ratio 300:1
Image Max H-View Angle +60 / -60
Image Max V-View Angle +40 / -65
Video Input
Analog Video Format None
Analog Video Signal RGB
Digital Video Standard Digital Visual Interface (DVI)
Audio Output
Type speaker(s) - Stereo - Integrated
Output Power / Channel 8.0 Watt
Input Device
Type None
Expansion / Connectivity
Interfaces 1.0 x Headphones - Output - Mini-phone stereo 3.5 mm - 1.0
Connections 1.0 x Display / video - Line-out - Mini-phone mono 3.5 mm - 1.0 , 1.0 x Audio - VGA - 24 pin digital DVI - 1.0 , 1.0 x Microphone - VGA - Mini-phone stereo 3.5 mm - 1.0 , 1.0 x Display / video - Input - 15 pin HD D-Sub (HD-15) - 1.0
Miscellaneous
Cables Included 1.0 x Microphone cable , 1.0 x Audio cable
Features Kensington MicroSaver security system
Compliant Standards FEMKO , ICES-003 , DDC-2B , NEMKO , DEMKO , CSA , PTB , C-Tick , UL 1950 , TCO '99 , TUV GS , EPA Energy Star , FCC Class B certified , SEMKO , VCCI Class B ITE , IEC950 , Plug and Play , DDC-1 , NOM
Power
Form Factor Internal
Voltage Required AC 120 V
Power Consumption Operational 45.0 Watt
Power Consumption Stand by / Sleep 2.3 Watt
Software / System Requirements
Software type Drivers amp; Utilities
Min Operating system None
Environmental Parameters
Operating humidity range 20 - 80%
