Specifications
CPU
- Socket 478 for Intel Pentium 4/ Celeron up to 3.06GHz+
- Intel Hyper-Threading Technology ready
Chipset
Intel 845PE
Intel ICH4
Front Side Bus
800 (overclocking) / 533 / 400 MHz
(*Note: A 800FSB CPU requires a PC3200 DDR DIMM. Intel Prescott CPUs can only support 533 MHz FSB on this motherboard. 800MHz FSB works with Intel Northwood processors only.)
Memory
2 x 184-pin DIMM Sockets support max. 2GB PC3200(overclocking)/PC2700/PC2100 non-ECC DDR SDRAM memory
(*Note: Obtain PC3200 DDR DIMMs only from ASUS qualified vendors for better system performance.)
Expansion Slots
1 x AGP 4X (1.5V only)
4 x PCI
Storage/RAID
2 x UltraDMA 100/66/33
Audio
ADI AD1888 SoundMAX 6-channel audio CODEC
Support S/PDIF out interface
LAN
Realtek RTL8101L 10/100 Mbps LAN PCI controller
USB
Integrated 6 USB2.0 ports
Overclocking Features
- ASUS JumperFree
- Flexible CPU Core Voltage Adjustments in 0.025V increments over defaults
- SFS (Stepless Frequency Selection) from 200MHz up to 300MHz at 1MHz increment
- Adjustable FSB/DDR ratio.
- ASUS C.P.R. (CPU Parameter Recall)
Special Features
Support S/PDIF out Interface
My Logo
ASUS C.P.R. (CPU Parameter Recall)
ASUS EZ Flash
ASUS CrashFree BIOS 2
Back Panel I/O Ports
1 x Parallel
1 x Serial
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x Audio I/O
1 x RJ45
1 x S/PDIF out Interface
4 x USB 2.0
BIOS
3Mb Flash EEPROM
AMI BIOS with enhanced ACPI,DMI,PnP,TCAV
SM BIOS 2.3, ASUS EZ Flash, ASUS C.P.R, ASUS
Industrial Standard
PCI 2.2, USB2.0
Manageability
WOL by PME,WOR by PME
Internal I/O Connectors
- 1 x USB 2.0 connector support additional 2 USB 2.0 ports
- CPU / Chassis FAN connectors
- Chassis Intrusion
- 20-pin ATX Power connector
- 4-pin ATX 12V Power connector
- CD / AUX audio in
- Game/MIDI port connector
- 20 Pin Panel connector
- Front Panel Audio connector
Power Requirement
ATX power supply (with 4-pin 12V plug)
Support Disc
Drivers
ASUS PC Probe
ASUS LiveUpdate Utility
Trend Micro PC-cillin 2002 anti-virus software (OEM version)
Accessories
User's manual
1 x UltraDMA cable
1 x FDD cable
I/O shield
Form Factor
ATX Form Factor 12"x 7.0"(30.5cm x 17.8cm)
CPU
- Socket 478 for Intel Pentium 4/ Celeron up to 3.06GHz+
- Intel Hyper-Threading Technology ready
Chipset
Intel 845PE
Intel ICH4
Front Side Bus
800 (overclocking) / 533 / 400 MHz
(*Note: A 800FSB CPU requires a PC3200 DDR DIMM. Intel Prescott CPUs can only support 533 MHz FSB on this motherboard. 800MHz FSB works with Intel Northwood processors only.)
Memory
2 x 184-pin DIMM Sockets support max. 2GB PC3200(overclocking)/PC2700/PC2100 non-ECC DDR SDRAM memory
(*Note: Obtain PC3200 DDR DIMMs only from ASUS qualified vendors for better system performance.)
Expansion Slots
1 x AGP 4X (1.5V only)
4 x PCI
Storage/RAID
2 x UltraDMA 100/66/33
Audio
ADI AD1888 SoundMAX 6-channel audio CODEC
Support S/PDIF out interface
LAN
Realtek RTL8101L 10/100 Mbps LAN PCI controller
USB
Integrated 6 USB2.0 ports
Overclocking Features
- ASUS JumperFree
- Flexible CPU Core Voltage Adjustments in 0.025V increments over defaults
- SFS (Stepless Frequency Selection) from 200MHz up to 300MHz at 1MHz increment
- Adjustable FSB/DDR ratio.
- ASUS C.P.R. (CPU Parameter Recall)
Special Features
Support S/PDIF out Interface
My Logo
ASUS C.P.R. (CPU Parameter Recall)
ASUS EZ Flash
ASUS CrashFree BIOS 2
Back Panel I/O Ports
1 x Parallel
1 x Serial
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x Audio I/O
1 x RJ45
1 x S/PDIF out Interface
4 x USB 2.0
BIOS
3Mb Flash EEPROM
AMI BIOS with enhanced ACPI,DMI,PnP,TCAV
SM BIOS 2.3, ASUS EZ Flash, ASUS C.P.R, ASUS
Industrial Standard
PCI 2.2, USB2.0
Manageability
WOL by PME,WOR by PME
Internal I/O Connectors
- 1 x USB 2.0 connector support additional 2 USB 2.0 ports
- CPU / Chassis FAN connectors
- Chassis Intrusion
- 20-pin ATX Power connector
- 4-pin ATX 12V Power connector
- CD / AUX audio in
- Game/MIDI port connector
- 20 Pin Panel connector
- Front Panel Audio connector
Power Requirement
ATX power supply (with 4-pin 12V plug)
Support Disc
Drivers
ASUS PC Probe
ASUS LiveUpdate Utility
Trend Micro PC-cillin 2002 anti-virus software (OEM version)
Accessories
User's manual
1 x UltraDMA cable
1 x FDD cable
I/O shield
Form Factor
ATX Form Factor 12"x 7.0"(30.5cm x 17.8cm)
