Specifications
CPU
Supports Intel® Core™2 Extreme Quad-Core / Core™2 Duo / Intel® Pentium® Extreme/ Intel® Pentium® D processors
Supports1333/1066/800 MHz FSB
Chipset
Northbridge: Intel® P35 Express Chipset
Southbridge: Intel® ICH9
Gigabit Lan Controller
8 Channels ALC888 Audio controller
Memory
Supports DDR2 1066*/800/667memory
Dual Channel architecture supports up to 8GB by 4 DIMM slots
* Please refer "Memory Support List" for memory support information.
Expansion Slots
1 PCI Express X16 slot
3 PCI Express X1 slots
3 PCI slots
Form Factor
ATX form factor, 305 x 210mm
Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x floppy disk drive connector
1 x IDE connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF out connector
3 x USB 2.0/1.1 headers (supports 6 ports)
1 x chassis intrusion header
1 x power LED header
Back Panel Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x parallel port
1 x coaxial S/PDIF Out connector
1 x optical S/PDIF Out connector
1 x serial port
6 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
BIOS
Supports Virtual DualBIOS
1 x 8 Mbit flash
Use of licensed AWARD BIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.3, ACPI 1.0b
Unique Features
Ultra Durable Motherboard
Over-clocking Enhanced
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.
To enable hot plug capability for the SATA connectors controlled by the ICH9 South Bridge, you must install Windows Vista (on ICH9, hot plug is supported in Windows Vista only) and configure the SATA connectors for AHCI mode. (Refer to manual Chapter 2, "BIOS Setup," "Integrated Peripherals," for details on enabling AHCI.)
CPU
Supports Intel® Core™2 Extreme Quad-Core / Core™2 Duo / Intel® Pentium® Extreme/ Intel® Pentium® D processors
Supports1333/1066/800 MHz FSB
Chipset
Northbridge: Intel® P35 Express Chipset
Southbridge: Intel® ICH9
Gigabit Lan Controller
8 Channels ALC888 Audio controller
Memory
Supports DDR2 1066*/800/667memory
Dual Channel architecture supports up to 8GB by 4 DIMM slots
* Please refer "Memory Support List" for memory support information.
Expansion Slots
1 PCI Express X16 slot
3 PCI Express X1 slots
3 PCI slots
Form Factor
ATX form factor, 305 x 210mm
Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x floppy disk drive connector
1 x IDE connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF out connector
3 x USB 2.0/1.1 headers (supports 6 ports)
1 x chassis intrusion header
1 x power LED header
Back Panel Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x parallel port
1 x coaxial S/PDIF Out connector
1 x optical S/PDIF Out connector
1 x serial port
6 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
BIOS
Supports Virtual DualBIOS
1 x 8 Mbit flash
Use of licensed AWARD BIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.3, ACPI 1.0b
Unique Features
Ultra Durable Motherboard
Over-clocking Enhanced
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
Due to most hardware/software vendors no longer offer support for Win9X/ME. If some vendors still has Win9X/ME drivers available, we will publish on website.
To enable hot plug capability for the SATA connectors controlled by the ICH9 South Bridge, you must install Windows Vista (on ICH9, hot plug is supported in Windows Vista only) and configure the SATA connectors for AHCI mode. (Refer to manual Chapter 2, "BIOS Setup," "Integrated Peripherals," for details on enabling AHCI.)
