Supports compatible Intel® Socket 478 processors
See our CPU Compatibility listing
Chipset
SiS651 + 962L
Front Side Bus
533/400MHz FSB
Memory
Single Channel 333MHz / 266MHz DDR DRAM x2 DIMMs, Max 2 GB
VGA on Die
Integrated SiS graphics
Expansion Slots
1 x AGP 4X, 3 x PCI, 1 x CNR
IDE
2 x ATA/133
Serial ATA(SATA)/RAID
N/A
Audio
5.1 channel AC97 (Realtek)
LAN
Integrated Fast Ethernet (10/100) MAC + PHY (Realtek)
IEEE1394
N/A
Back Panel I/O Ports
1 x PS/2 keyboard
1 x PS/2 mouse
1 x RJ45 (LAN)
4 x USB 2.0
1 x line-in/line-out/mic (audio)
1 x parallel (SPP/ECP/EPP)
1 x COM (16550-compatible UART)
1 x VGA (integrated video)
Internal I/O Connectors
1 x floppy disk drive
Front audio header
1 x USB 2-port header, ver. 2.0
BIOS Features
2Mb flash EEPROM w/ PnP, ACPI, WfM, DMI 2.0,
Support CD
Standards/Manageability
Special Features
Wake-on-LAN (WOL), suspend-to-RAM (STR, S3), suspend-to-disk (STD, S4), SuperUtilities - SuperBoot, SuperBIOS-Protect, SuperStep, SuperLogo, and SuperUpdate
Form Factor
microATX, 9.6'' x 9.6''
