Intel® Core™ i7-3630QM

Specifications

-Essentials
Processor Number i7-3630QM
Status Launched
Launch Date Q3'12
Lithography 22 nm
Recommended Customer Price $378.00
-Performance
# of Cores 4
# of Threads 8
Processor Base Frequency 2.40 GHz
Max Turbo Frequency 3.40 GHz
Cache 6 MB SmartCache
Bus Speed 5 GT/s DMI
TDP 45 W
-Supplemental Information
Embedded Options Available No
Conflict Free Yes
Datasheet Link
-Memory Specifications
Max Memory Size (dependent on memory type) 32 GB
Memory Types DDR3/L/-RS 1333/1600
Max # of Memory Channels 2
Max Memory Bandwidth 25.6 GB/s
ECC Memory Supported ‡ No
-Graphics Specifications
Processor Graphics ‡ Intel® HD Graphics 4000
Graphics Base Frequency 650.00 MHz
Graphics Max Dynamic Frequency 1.15 GHz
Graphics Output eDP/DP/HDMI/SDVO/CRT
Intel® Quick Sync Video Yes
Intel® InTru™ 3D Technology Yes
Intel® Wireless Display Yes
Intel® Flexible Display Interface (Intel® FDI) Yes
Intel® Clear Video HD Technology Yes
# of Displays Supported ‡ 3
Device ID 0x166
-Expansion Options
PCI Express Revision 3.0
PCI Express Configurations ‡ 1x16, 2x8, 1x8 2x4
Max # of PCI Express Lanes 16
-Package Specifications
Sockets Supported FCPGA988
Max CPU Configuration 1
TJUNCTION 105 C
Package Size 37.5 x 37.5mm (rPGA988B)
Low Halogen Options Available See MDDS
-Advanced Technologies
Intel® Turbo Boost Technology ‡ 2.0
Intel® vPro Technology ‡ No
Intel® Hyper-Threading Technology ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ No
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions AVX
Intel® My WiFi Technology Yes
4G WiMAX Wireless Technology Yes
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Intel® Demand Based Switching No
Thermal Monitoring Technologies Yes
Intel® Fast Memory Access Yes
Intel® Flex Memory Access Yes
Intel® Identity Protection Technology ‡ Yes
-Intel® Data Protection Technology
Intel® AES New Instructions Yes
Secure Key Yes
-Intel® Platform Protection Technology
Trusted Execution Technology ‡ No
Execute Disable Bit ‡ Yes
Anti-Theft Technology Yes
