Intel Pentium G2020, LGA1155

Specifications

-Essentials
Processor Number G2020
Status End of Life
Launch Date Q1'13
Lithography 22 nm
Recommended Customer Price $64.00
-Performance
# of Cores 2
# of Threads 2
Processor Base Frequency 2.90 GHz
Cache 3 MB SmartCache
Bus Speed 5 GT/s DMI
TDP 55 W
-Supplemental Information
Embedded Options Available No
Conflict Free Yes
Datasheet Link
-Memory Specifications
Max Memory Size (dependent on memory type) 32 GB
Memory Types DDR3 1333
Max # of Memory Channels 2
Max Memory Bandwidth 21 GB/s
ECC Memory Supported ‡ Yes
-Graphics Specifications
Processor Graphics ‡ Intel® HD Graphics
Graphics Base Frequency 650.00 MHz
Graphics Max Dynamic Frequency 1.05 GHz
Intel® Quick Sync Video No
Intel® InTru™ 3D Technology No
Intel® Wireless Display No
Intel® Clear Video HD Technology No
# of Displays Supported ‡ 3
-Expansion Options
PCI Express Revision 2.0
PCI Express Configurations ‡ up to 1x16, 2x8, 1x8 & 2x4
-Package Specifications
Sockets Supported FCLGA1155
Max CPU Configuration 1
Thermal Solution Specification 2011C
Package Size 37.5mm x 37.5mm
Low Halogen Options Available See MDDS
-Advanced Technologies
Intel® Turbo Boost Technology ‡ No
Intel® vPro Technology ‡ No
Intel® Hyper-Threading Technology ‡ No
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ No
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions SSE4.1/4.2
Intel® My WiFi Technology No
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
-Intel® Data Protection Technology
Intel® AES New Instructions No
Secure Key No
-Intel® Platform Protection Technology
Trusted Execution Technology ‡ No
Execute Disable Bit ‡ Yes
Anti-Theft Technology No
