3Com 3CGSU08

Layer 2
8 portů autosensing 10/100/1000 Ethernet
8 RJ-45 10BASE-T/100BASE-TX/1000BASE-TX
Auto MDI/MDIX na všech portech
half/full duplex
podpora prioritizace dat dle 802.1p
bez managementu
podpora Jumbo Frame
indikátory LED
vyhovuje EMC dle normy EN 55022, třída B (domácí a kancelářské použití)
Rozměry: 178 x 30.2 x 108 mm.
Hmotnost: 310 g.

Compact, Streamlined, Affordable Gigabit Switching for Small Offices with Big Demands
The 3Com® Gigabit Switch 8 is designed for small offices and remote branch offices requiring high network performance to exchange large data files and images, and access real-time information or connect to high-speed servers or a high-speed network backbone. Featuring autosensing and auto MDI/MDIX on all ports, the Gigabit Switch 5 is delivered in a futuristic, compact and streamlined enclosure. With a high quality dark gun metal grey look these switches exude quality, the 3Com logos "light up" on power up and they feature illuminating blue LEDs.

The 3Com Gigabit Switch 8 automatically finds the fastest connection speed, the autosensing 10/100/1000 ports automatically adjust to the speed of network devices communicating at 1000, 100, or 10 Mbps, so the switch can accommodate a range of workgroup applications. All that is needed is to connect the power and Ethernet cables.

There is no software to configure. Easy to set up these switches feature a fan-less design which provides silent operation. With a choice of 8 ports you can expand your network by adding more computers or devices with speeds up to 2000 Mbps per port in full-duplex mode.

The 3Com Gigabit Switch 8 offers high-speed, high-quality, reliable, affordable networking with a style that will accommodate any office environment.
For those requiring a smaller port count a 5 port version of this switch is available with similar features, the 3Com Gigabit Switch 5.

Auto-speed sensing 10/100/1000 Mbps connectivity. Enables connection at 1000 Mbps, 100 Mbps and 10 Mbps, ensuring optimum throughput for bandwidth intensive applications and compatibility with legacy equipment.
Full-duplex support of your network. Allows full, two-way data transfer, doubling the effective bandwidth.
FCC Class B certified. Certified for home and office use (more stringent than Class A certification).
Auto MDI/MDIX on every port. Eliminates most common cabling problems, whether the port is connected to a server, PC, another switch or hub.
Jumbo Frame support up to 9k, for reduced network load.
Front panel LEDs. Provides immediate notification of network use without requiring special technical knowledge.
Operating system independence. Supports maximum integration of different operating systems within a network-no extra configuration of the network is required.
Plug-and-Play convenience. For hassle-free installation, simple setup, no complicated configuration is required.
Silent operation. No-fan design ensures there is no noise disturbance from the switches.
2-Year limited warranty. Provides the on-going warranty support that businesses need.
Product Specifications

Total ports: 8 autosensing 10/100/1000 Ethernet
Media interfaces: 8 RJ-45 10BASE-T/100BASE-TX/1000BASE-TX
Ethernet switching features: Store-and-forward; full-/half-duplex auto-negotiation; 802.1p traffic prioritization (priority queuing)
Regulatory/Agency Approvals:
EMC:
CFR Title 47, FCC Part 15, Subpart B
Sections 15, 107 & 15, 109 Class B
ICES-003 Class B
EN 55022: Class B
EN 61000-3-2: 2000
EN 61000-3-3:1995
EN 61000-3-11
CISPR 22: 2003-04-10 Class B
RRL

Safety:
UL60950-1
CSA 22.2 No60950-1
EN60950-1
IEC6095-1

Environmental Specifications:
Operating temperature: 0o to 40oC (32o to 105oF)
Operating Humidity: 10% to 90% (non-condensing humidity)
Storage Humidity: 0% to 95%

Dimensions:
Width: 178 mm (7.0 in)
Height: 30.20 mm (1.18 in)
Depth: 108 mm (4.25 in)
Weight: 310g (10.93 ounces)
Power: 4.9 Watts
Package Contents

3Com Gigabit Switch 8
Power adapter

3Com® OfficeConnect® Gigabit Switch 8
Product * 3C1670800A
