ASUS F1A55-M

APU:
*AMD® A-& E2- series Accelerated Processor with AMD Radeon™ HD 6000 Series Graphics,Up to 4 CPU cores, FM1 Package
*AMD Turbo Core Technology 2.0 Supports*
*DirectX® 11 Supports
*The AMD®Turbo Core Technology 2.0 Support depends on the APU types

Čipová sada: AMD® A55 FCH

Paměť:
*2 x DDR3 DIMM, max. 32GB, DDR3 1866/1600/1333/1066 MHz, non-ECC un-buffered memory Dual Channel memory architecture
** The Max. 32 GB memory capacity can be supported with DIMMs of 16GB (or above). ASUS will update QVL once the DIMMs are available on the market.
*** Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)

Grafika:
*Integrated AMD Radeon™ HD 6000 Series Graphics in the Llano APU
*Supports D-Sub with max. resolution 1920 X 1600@60 HZ(16:10)
*Supports Microsoft® DirectX 11

Multi-GPU Support:
*Supports LucidLogix Virtu MVP Technology*
* LucidLogix Virtu MVP supports Windows 7 operating systems.

Rozšiřující sloty:
1x PCI Express 2.0 x16 slot
1 x PCI Express 2.0 x1 slot
1 x PCI slot

Úložný prostor:
*AMD® A55 FCH -4x Serial ATA 3Gb/s connectors(blue) with RAID 0, RAID 1,RAID 10 and JBOD support

LAN: Qualcomm Atheros® 8161 Gigabit LAN controller

Zvuk:
*Realtek® ALC 887 8-Channel High Definition Audio CODEC
*Use a chassis with HD audio module in the front panel to support an 8-channel audio output.

USB:
*AMD®A55 FCH -8 USB2.0/1.1 ports (4 ports at back panel, 4 ports at mid-board)

Speciální funkce Asus:
*Hybrid DIGI+VRM
*EPU
*Network iControl
*AI Suite II
*Anti-Surge
*ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
*ASUS Fan Xpert
*ASUS CrashFree BIOS 3
*ASUS EZ Flash 2
*ASUS MyLogo 2
*The Network iControl feature does not support Windows® XP/Vista operating systems.

Zadní vstupy a výstupy:
*1 x PS/2 Keyboard
*1 x PS/2 Mouse
*1 x COM port
*1 x D-Sub Output port
*1 x LAN (RJ45) port
*4 x USB 2.0/1.1 ports
*8 channel Audio 3 Jacks
*2 x USB 2.0 connectors support additional 4 USB 2.0 ports

Vnitřní vstupy a výstupy:
*1 x High Definition front panel audio connector
*4 x SATA 3Gb/s connectors
*1 x System Panel connector
*1 x Internal Speaker connector
*1 x CPU Fan connectors
*1 x Chassis Fan connectors
*24-pin EATX power connector
*4-pin ATX 12V Power connector

BIOS: 64 Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS V2.6, ACPI V2.0a

Příslušenství:
*2 x Serial ATA 3Gb/s cables
*1x IO Shield
*User's manual

Support DVD:
*Drivers
*ASUS utilities
*ASUS Update
*Anti-virus software (OEM version)

Form factor:
*uATX Form Factor,8.9"x 7.3" (22.6cm x 18.6cm)

+I/O shield krytka
