AMD A6-5400

General information
Type CPU / Microprocessor
Market segment Desktop
Family AMD A6-Series
Model number ? A6-5400K
CPU part numbers
AD540KOKA23HJ is an OEM/tray microprocessor
AD540KOKHJBOX is a boxed microprocessor with fan and heatsink
Frequency ? 3.6 GHz / 3600 MHz
Maximum turbo frequency 3.8 GHz / 3800 MHz
Package 904-pin organic lidded micro Pin Grid Array (UOF904)
Socket Socket FM2
Size 1.57" x 1.57" / 4cm x 4cm
Introduction date August 2012 (shipped in OEM PCs)
October 2, 2012 (boxed processors)
Price at introduction $67
Architecture / Microarchitecture
Instruction set x86
Microarchitecture Piledriver
Platform Virgo
Processor core ? Trinity
Core stepping ? TN-A1
CPUID 610F01
Manufacturing process 0.032 micron
Data width 64 bit
The number of CPU cores 2
The number of threads 2
Floating Point Unit Integrated (shared between two cores in each module)
Level 1 cache size ? 64 KB instruction cache
2 x 16 KB data caches
Level 2 cache size ? 1 MB
Level 3 cache size None
Cache latency 3 (L1 cache)
Multiprocessing Uniprocessor
Extensions & Technologies
MMX instructions
Extensions to MMX
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 ?
SSE4a ?
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
BMI1 / Bit Manipulation instructions 1
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
FMA4 / 4-operand Fused Multiply-Add instructions
TBM / Trailing Bit Manipulation instructions
XOP / eXtended Operations instructions
AMD64 / AMD 64-bit technology ?
AMD-V / AMD Virtualization technology
Turbo Core 3.0 technology
Security Features EVP / Enhanced Virus Protection ?
Low power features PowerNow!
Integrated Graphics Processing Unit
GPU Type Radeon HD 7540D
Shader cores 192
Base frequency (MHz) 760
Integrated peripherals / components
Memory controller The number of controllers: 1
Memory channels (per controller): 2
Memory channels (total): 2
Supported memory: DDR3-1866
Other peripherals
PCI Express 2.0 interface
Unified Video Decoder 3.2
Electrical / Thermal parameters
V core ? 0.825V - 1.475V
Maximum operating temperature ? 70°C
Thermal Design Power ? 65 Watt
