AMD Sempron 2500+ Socket A/462

General information
Type CPU / Microprocessor
Market segment Desktop
Family AMD Sempron
Model number ? 2500+
CPU part numbers
SDA2500DUT3D is an OEM/tray microprocessor
SDA2500BOX is a boxed microprocessor with fan and heatsink
Stepping codes BCXJB BIXJB
Frequency ? 2500+ (rated)
1750 MHz (actual)
Bus speed ? 333 MHz
Clock multiplier ? 10.5
Package 453-pin organic PGA
1.95" x 1.95" (4.95 cm x 4.95 cm)
AMD Package numbers 27648
28104
Socket Socket 462 / Socket A
Introduction date July 28, 2004
Price at introduction $74
Architecture / Microarchitecture
Instruction set x86
Microarchitecture K7
Processor core ? Thoroughbred (Model 8)
CPUID 681
Manufacturing process 0.13 micron
Data width 32 bit
The number of CPU cores 1
The number of threads 1
Floating Point Unit Integrated
Level 1 cache size ? 64 KB 2-way set associative instruction cache
64 KB 2-way set associative data cache
Level 2 cache size ? Full speed on-die 256 KB 16-way set associative exclusive cache
Multiprocessing Uniprocessor
Extensions & Technologies
MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
Low power features
Halt state
Stop Grant states
Sleep state ?
Probe state
Integrated Graphics Processing Unit
None
Electrical / Thermal parameters
V core ? 1.6V
Minimum/Maximum operating temperature ? 0°C - 90°C
Typical/Maximum power dissipation 55.9 Watt / 62 Watt
