Popis
P5M2 is based on latest Intel® Xeon® 3000 / CoreTM 2 Duo processor, Intel® 3000 MCH, Intel® ICH7R and Intel® 6702 PXH 64-bit PCI Hub chipset, which achieves 102% better performance (SPECjbb2005) and 69% reduction in processor power (65W compared with 110W) than its predecessor, will provide immediate dual-processor level performance scale-up.
Processor / System Bus
1 * Socket LGA775
Intel® Xeon® processor 3000 sequence or
Intel® CoreTM 2 Duo processors
FSB 533/ 800/ 1066MHz EM64T 4M L2 cache
Core Logic
Intel® 3000 MCH
Intel® ICH7R
Intel® 6702 PXH 64-bit PCI Hub
Form Factor
ATX, 12" * 9.6"
ASUS Features
Cooling Strategy: Smart Fan II
Rack Ready (Rack and Pedestal dual use): â
ASWM2.0: â
Memory
Total Slots: 4
Capacity: Maximum up to 8GB
Memory Type: Dual Channel ECC / Non-ECC Unbuffered DDR2 533 / 667
Memory Size: 256MB, 512 MB, 1 GB, 2GB
Expansion Slots
Total Slots: 5
Slot 1: 1 * PCI 32bit/ 33MHz
Slot 2: -
Slot 3: -
Slot 4: -
Slot 5: 1 * PCI-X 133 / 100MHz
Slot 6: 1 * PCI-X 133 / 100MHz
Slot 7: 1 * PCI-E x16 (x 8 link)
Additional Slot 1: 1 * SODIMM socket for optional management card
Storage
IDE Controller:
Intel® ICH7R:
1 * IDE support UltraATA 33 / 66 / 100
SATA Controller:
Intel® ICH7R:
4 * SATAII 300MB/s ports
Intel® Matrix Storage (Windows) supports RAID 0, 1, 0+1, RAID 5
LSI® MegaRAID (Linux/Windows) supports RAID 0, 1, 0+1
Networking
LAN: 2 * Broadcom® BCM5721 PCI-E Gb LAN
Graphic
VGA: ATI® ES1000 PCI Display Controller/ 32MB
Onboard I/O Connectors
Floppy Connector: 1
PSU Connector: SSI 24-pin + 12V 4-pin
Management Connector: SODIMM socket for optional management card
USB Connectors: 1 (support 2 USB ports)
Fan Header: 6 * 4pin
SMBus: 1
Chassis Intruder: 1
Front LAN LED: 2
Serial Port Header: 1
Rear I/O Connectors
External Serial Port: 1
External USB Port: 2
VGA Port: 1
RJ-45: 2
PS/2 KB/Mouse: 1
Management Solution
Software: ASWM2.0
Monitoring
CPU Temperature: â
FAN RPM: â
EMI
US (FCC, CFR47 Part 15, Class B)
Europe (CE, EN55022 amp; EN55024)
Environment
Operation temperature: 10â ~ 35â
Non operation temperature: -40â ~ 70â
Non operation humidity: 20% ~ 90% ( Non condensing)
Processor / System Bus
1 * Socket LGA775
Intel® Xeon® processor 3000 sequence or
Intel® CoreTM 2 Duo processors
FSB 533/ 800/ 1066MHz EM64T 4M L2 cache
Core Logic
Intel® 3000 MCH
Intel® ICH7R
Intel® 6702 PXH 64-bit PCI Hub
Form Factor
ATX, 12" * 9.6"
ASUS Features
Cooling Strategy: Smart Fan II
Rack Ready (Rack and Pedestal dual use): â
ASWM2.0: â
Memory
Total Slots: 4
Capacity: Maximum up to 8GB
Memory Type: Dual Channel ECC / Non-ECC Unbuffered DDR2 533 / 667
Memory Size: 256MB, 512 MB, 1 GB, 2GB
Expansion Slots
Total Slots: 5
Slot 1: 1 * PCI 32bit/ 33MHz
Slot 2: -
Slot 3: -
Slot 4: -
Slot 5: 1 * PCI-X 133 / 100MHz
Slot 6: 1 * PCI-X 133 / 100MHz
Slot 7: 1 * PCI-E x16 (x 8 link)
Additional Slot 1: 1 * SODIMM socket for optional management card
Storage
IDE Controller:
Intel® ICH7R:
1 * IDE support UltraATA 33 / 66 / 100
SATA Controller:
Intel® ICH7R:
4 * SATAII 300MB/s ports
Intel® Matrix Storage (Windows) supports RAID 0, 1, 0+1, RAID 5
LSI® MegaRAID (Linux/Windows) supports RAID 0, 1, 0+1
Networking
LAN: 2 * Broadcom® BCM5721 PCI-E Gb LAN
Graphic
VGA: ATI® ES1000 PCI Display Controller/ 32MB
Onboard I/O Connectors
Floppy Connector: 1
PSU Connector: SSI 24-pin + 12V 4-pin
Management Connector: SODIMM socket for optional management card
USB Connectors: 1 (support 2 USB ports)
Fan Header: 6 * 4pin
SMBus: 1
Chassis Intruder: 1
Front LAN LED: 2
Serial Port Header: 1
Rear I/O Connectors
External Serial Port: 1
External USB Port: 2
VGA Port: 1
RJ-45: 2
PS/2 KB/Mouse: 1
Management Solution
Software: ASWM2.0
Monitoring
CPU Temperature: â
FAN RPM: â
EMI
US (FCC, CFR47 Part 15, Class B)
Europe (CE, EN55022 amp; EN55024)
Environment
Operation temperature: 10â ~ 35â
Non operation temperature: -40â ~ 70â
Non operation humidity: 20% ~ 90% ( Non condensing)
