ASUS P5N-T Deluxe

CPU
Intel® Socket 775 Core™2 Quad/Core™2 Extreme/Core™2 Duo/Pentium® Extreme/Pentium® D Compatible with Intel® 05B/05A/06 processors

Support Intel® 45nm CPU
Chipset
NVIDIA nForce 780i SLI
Front Side Bus
1333/1066/800 MHz
Memory
4 x DIMM, Max. 8 GB, DDR2 1200/1066/800/667 Non-ECC,Un-buffered Memory

Dual Channel memory architecture

*When installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
Expansion Slots
3 x PCIe x16 (blue @PCIe2.0 x16 mode, black @PCIe x16 mode) supports SLI Technology

2 x PCIe x1

1 x PCI
Storage
Southbridge

1 xUltraDMA 133/100/66

6 xSATA 3 Gb/s ports NVIDIA® MediaShield™ RAID

Support RAID 0,1,0+1,5,JBOD configuration across Serieal ATA drives

Marvell 88SE6111

1 xExternal SATA
Scalable Link Interface (SLI™)
Support three identical NVIDIA SLI-Ready graphics cards (all at x16 mode)
LAN
Marvell88E1116 PCIe Gigabit LAN PHY featuring AI NET2
Audio
ADI® AD1988B 8 -Channel High Definition Audio CODEC

Coaxial / Optical S/PDIF out ports

ASUS Noise Filter

Support Jack-Sensing, Enumeration, Multi-streaming
IEEE 1394
VIA6308P controller supports 2 x 1394a ports
USB
10 USB 2.0 ports (6 ports at mid-board, 4 ports at back panel)
ASUS Unique Features
ASUS Power Saving Solution

- ASUS EPU (Energy Processing Unit)

- ASUS 3rd Generation 8-phase Power

- ASUS AI Nap

ASUS AI Lifestyle

- ASUS AI Direct Link

ASUS Quiet Thermal Solution

- ASUS Fanless Design: Stack Cool 2

- ASUS Q-Fan 2

- ASUS Optional Fan for Water-cooling or Passive-Cooling only

- ASUS Fanless Design: Sophisticated Heat-pipe solution

ASUS Crystal Sound

- ASUS Noise Filter

ASUS EZ DIY

- ASUS Q-Connector

- ASUS Q-Shield

- ASUS O.C. Profile

- ASUS CrashFree BIOS 2

- ASUS EZ Flash 2
Overclocking Features
Intelligent overclocking tools

- ASUS AI Booster Utility

Precision Tweaker 2

- vDIMM: 64 -step DRAM voltage control

- vCore: Adjustable CPU voltage at 0.00625V increment

- vChipset (N.B.) 64-step voltage control

- vChipset (S.B.): 16 step Chipset voltage control

- vHT (Hyper Transport): 41-step Hyper Transport voltage control

SFS (Stepless Frequency Selection)

- FSB tuning from 133MHz up to 800MHz at 1MHz increment

- Memory tuning from 400MHz up to 2600MHz

- PCI Express frequency tuning from 100MHz up to 200MHz at 1MHz increment

Overclocking Protection

- ASUS C.P.R.(CPU Parameter Recall)
Special Features
Multi-language BIOS

ASUS MyLogo 3
Back Panel I/O Ports
1 x PS/2 Keyboard

1 x PS/2 Mouse

1 x External SATA

1 x S/PDIF Out

1 x IEEE 1394a

1 x LAN(RJ45) port

4 x USB 2.0/1.1

8 -Channel Audio I/O
Internal I/O Connectors
3 x USB connectors support additional 6 USB ports

1 x Floppy disk drive connector

1 x IDE connector

6 x SATA connectors

1 x IEEE 1394a connector

1 x CPU Fan connector

1 x Chassis Fan connector

2 x Power Fan connector

1 x 8-pin ATX 12V Power connector

24 Power connector

1 x COM connector

20 Pin Panel connector

Front panel audio connector

Chassis Intrusion connector

System Panel

CD audio in
BIOS
8 Mb Flash ROM

DMI 2.0

AMI BIOS

PnP

WfM 2.0

SM BIOS 2.3

Multi-language BIOS
Manageability
WOL by PME,WOR by PME,Chasis Intrusion,AI NET2 PXE
Accessories
User's manual

1 x 2-port USB2.0 module / 1-port 1394 module

1 x UltraDMA 133/100/66 cable

1 x Floppy disk drive cable

6 x SATA cable

1 x SATA power cable for 2 devices

3 in 1 Q-connector

1 x Optional Fan for Water-Cooling or Passive-Cooling only

1 x 3-Way SLI bridge card

1 x 2-Way SLI bridge cable

ASUS Q-Shield
Support Disc
Drivers

ASUS PC Probe II

ASUS AI Suite

Anti-virus software (OEM version)

ASUS Update

Image Editing Suite
Form Factor
ATX Form Factor

12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
