CPU
AMD Athlon 64 X2, Athlon 64 and Sempron in the Socket AM2 package.
Please refer to CPU Support for compatible CPU; the above description is for reference only.
Hyper Transport Bus
HyperTransport 1.0/2.0 supporting speed up to 1GHz (2000MT/s)
Chipset
NVIDIA MCP61 (P/S/V)
Main Memory
Supports Dual Channel DDR2 533/667/800
- 2 DDR2 DIMMs (240pin / 1.8V)
- Supports a maximum memory size up to 8GB.
Slots
One PCI Express x16 slot. (K9N6PGM-FI/F)
One PCI Express x1 slot.
Two PCI slots (support 3.3v/5v PCI bus interface).
MSI Reminds You...
K9N6SGM-V doesn't support ATI X550, x1050, X700, X800, X850 and X1800XL series graphic cards.
On-Board IDE
One IDE port by NVIDIA MCP61 (P/S/V)
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
- Can connect up to two IDE devices
On-Board SATA
Two SATA II ports by NVIDIA MCP61 (P/S/V)
- Supports storage and data transfers at up to 3Gb/s
RAID Function
- SATA II 1~2 supports RAID 0, 1 mode by NVIDIA MCP61 (P/S/V)
MSI Reminds You...
The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk.
Audio
⢠Chipset integrated by Realtek ALC861/883/888
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec
LAN
Supports 10/100 Fast Ethernet by Realtek 8201CL (K9N6SGM-V, K9N6VGM-V)
Supports 10/100/1000 Fast Ethernet by Realtek 8211BL-GR (K9N6PGM-FI/F)
IEEE1394 / FireWire
Chipset integrated by VIAVT6308P
- Transfer rate is up to 400Mbps
Internal I/O Connectors
- ATX 24-pin power connector
- 4-pin ATX 12V power connector
- CPU / System FAN connectors
- CD-in connector
- 1 x Floppy disk drive connector
- 2 x SATA II connectors
- 1 x ATA133 connectors
- 2 x USB 2.0 connector support additional 4 ports
- 1 x IEEE1394 connector support additional 1 ports (Optional)
- SPDIF-Out connector
- Front panel connector
- Front panel audio connector
- Chassis intrusion switch connector
- Clear CMOS Jumper
MSI Reminds You...
The floppy disk cable will be optional.
Back Panel I/O Ports
- 1 x PS/2 Keyboard
- 1 x Parallel port
- 1 x Serial port
- 1 x PS/2 Mouse
- 1 x VGA port
- 1 x IEEE1394 port (Optional)
- 1 x 6 in 1 audio jack
- 4 x USB 2.0
- 1 x RJ45 LAN Jack
Dimension
24.4cm(L) x 20.5cm(W) Micro-ATX Form Factor
Mounting
6 mounting holes.
