SPECIFICATION
Processor
Support Socket 478 for Intel(R) Pentium(R) 4 1.5GHz~3.06GHz or faster Processor
400/533MHz system interface speed
Chipset
SIS 650GX North Bridge + SIS 962L South Bridge chipsets
MuTIOL® Delivering 533MB/s Bandwidth
Memory
Supports two 184-pin DDR DIMM maximum size up to 2GB
Support DIMMs of DDR266/DDR200
Graphics Adapter Slot
Support AGP4X Interface
Embedded 3D Ultra AGP VGA
Integrated Real256TM 2D/3D Graphics Accelerator
Shared memory architecture allows a maximum of 64 MB main memory to act as frame buffer
Embedded USB2.0
480 Mbps data capacity
Backwards compatible with USB 1.1
Compliant with Intel's Enhanced Host Controller Interface
Specification Revision 0.95
Embedded LAN on board
10/100Mbps Fast Ethernet LAN on board
Supports IEEE 802.3 and 802.3u standards
Fully compliant ANSI X3.263 TP-PMD physical sub-layer
Audio
AC97 Codec on board to provide software audio solution
6CH DAC, applicable for leading motherboard chipsets.
48 LQFP package(pin to pin compatible with 2-channel CODEC) and 24-lead TSSOP package.
Two Ultra DMA IDE Ports
Supports two IDE ports up to 4 ATAPI devices
Supports up to PIO Mode 4 up to 16.6MBps, Multi Mode 4 up to 133MBps with bus mastering
Bus Architecture
One AGP4x slot
Five 32-bit PCI slots with full master sharing controller (Rev 2.2 compliant)
One CNR slot
I/O Interface
PS/2 Mini-DIN keyboard and mouse ports
Six USB ports (four backpanel ports, onboard USB headers providing two extra ports)
One D-SUB 9-pin male serial ports
One D-SUB 15-pin female VGA port
One D-SUB 25-pin female Printer port
One RJ45 LAN Port
Audio Line-out, Line-in and Mic-in jacks
Form Factor
304mm x 190mm, 4 Layers
ATX form factor
