Popis
Model
Brand
ASUS
Model
P4B533
Supported CPU
CPU Socket Type
478
CPU Type
Pentium 4 / Celeron
FSB
800(Overclocking) /533/400MHz
Supported CPU Technologies
Hyper-Threading Technology
Chipsets
North Bridge
Intel 845E
South Bridge
Intel ICH4
Memory
Number of Memory Slots
2Ã184pin
Memory Standard
DDR 400* /333*/266/200,overclocking feature support DDR 400* /333*
Maximum Memory Supported
2GB
Expansion Slots
AGP Slots
1 x AGP 4X
PCI Slots
4
Storage Devices
PATA
2 x ATA100 4 Dev. Max
Onboard Video
Onboard Video Chipset
None
Onboard Audio
Audio Chipset
ADI AD1888
Audio Channels
6 Channels
Onboard LAN
LAN Chipset
Realtek
Max LAN Speed
10/100Mbps
Rear Panel Ports
PS/2
2
COM
1
LPT
1
USB 1.1/2.0
4 x USB 2.0
Audio Ports
3 Ports
Internal I/O Connectors
Onboard USB
2 x USB 2.0
Physical Spec
Form Factor
ATX
Dimensions
12" x 7"
Brand
ASUS
Model
P4B533
Supported CPU
CPU Socket Type
478
CPU Type
Pentium 4 / Celeron
FSB
800(Overclocking) /533/400MHz
Supported CPU Technologies
Hyper-Threading Technology
Chipsets
North Bridge
Intel 845E
South Bridge
Intel ICH4
Memory
Number of Memory Slots
2Ã184pin
Memory Standard
DDR 400* /333*/266/200,overclocking feature support DDR 400* /333*
Maximum Memory Supported
2GB
Expansion Slots
AGP Slots
1 x AGP 4X
PCI Slots
4
Storage Devices
PATA
2 x ATA100 4 Dev. Max
Onboard Video
Onboard Video Chipset
None
Onboard Audio
Audio Chipset
ADI AD1888
Audio Channels
6 Channels
Onboard LAN
LAN Chipset
Realtek
Max LAN Speed
10/100Mbps
Rear Panel Ports
PS/2
2
COM
1
LPT
1
USB 1.1/2.0
4 x USB 2.0
Audio Ports
3 Ports
Internal I/O Connectors
Onboard USB
2 x USB 2.0
Physical Spec
Form Factor
ATX
Dimensions
12" x 7"
