CHIPSET
SiS® 730S Chipset
Processor
On board AMD® Duron CPU
200 / 100MHz
GRAPHICS
SiS300 GPU
Main Memory
2 SDRAM DIMMs
Supports PC133 / PC100
Max. 1GB
EXPANSION SLOT
2 x PCI slots
1 AGP (4X)
1 x AMR slot
Sound
VIA® VT1612A AC'97 Audio CODEC
LAN
VIA® VT6103 Fast Ethernet 10/100 PHY / Transceiver (optional)
Back Panel I/O Ports
1 PS/2 Mouse
1 PS/2 Keyboard
1 Parallel
1 Serial
1 VGA
1 IEEE 1394A
1 LAN
4 USB
1 Line-in
1 Line-out
Microphone
Internal I/O Connectors
LAN wake up connector
Modem wake up connector
20-pin ATX power connector
Front Panel MIC/Speaker out header
2 USB headers
Super I/O
ITE IT8705F
IDE
2 UltraDMA 100 / 66 / 33
USB
4 USB 1.1
BIOS
AMI 2Mb Flash EEPROM
FORM FACTOR
microATX
Board Size
244 mm x 220 mm
