PCCHIPS M852 REV:1.0 mainboard

Specification

CPU Socket A for AMD Athlon XP / Sempron processor

FSB 333/266/200 MHz

Chipset VIA KT400A/VT8235

Memory 2 x 184-pin DIMM sockets support two 2.5V DDR SDRAMs (DDR400/333/266)

Maximum: 2GB

Expansion Slots 1 x AGP 8X

5 x PCI

1 x CNR

LAN VIA VT6103 10/100Mbps Fast Ethernet PHY

Audio VIA VT1612A 2-channel audio Codec

Compliant with AC97 2.2 specification

IDE 2 x ATA 133/100/66

Back Panel I/O Ports 1 x PS/2 keyboard

1 x PS/2 mouse

1 x Parallel Port

1 x Serial Port

4 x USB 2.0 Ports

1 x RJ 45 Port

1 x Audio I/O (Line-in, Line-out and Mic-in)

Internal I/O Connectors & Headers 20-pin ATX power supply connector

1 x Floppy connector-support 360K~2.88M Byte, 3 Mode FDDs or LS120

1 x IrDA for SIR header

1 x USB header support additional 2 USB2.0 ports

1 x Front panel switch/LED header

1 x Speaker header

CPU / CAS FAN headers

1 x CD in header

1 x Front panel audio header

System BIOS Award 2Mb Flash ROM

Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI

Full support for ACPI revision 1.0 specification

Form Factor ATX Form Factor, 305*190mm
