Gigabyte GA-G33M-DS2R

CPU
Supports Intel® Core™2 Extreme/ Core2™ Quad / Core™2 Duo / Intel® Pentium® Extreme/ Intel® Pentium® D processor
Supports 1333/1066/800 MHz FSB
Chipset
Northbridge: Intel® G33 Express Chipset
Southbridge: Intel® ICH9
Realtek RTL8111B LAN Controller
Realtek ALC889A 8 Channel Audio Codec
Memory
Supports DDR2 800/667 memory
Dual Channel architecture support up to 8GB by 4 DIMM slots
Expansion Slots
1 x PCI Express X16 slot
1 x PCI Express X4 slot
2 x PCI slots
Internal I/O Connectors
1 x 24-pin ATX power connector
1 x 4-pin ATX 12V power connector
1 x floppy connector
1 x IDE connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
1 xsystem fan header
1 x front panel header
1 x front audio header
1 x CD In connector
4 x USB 2.0/1.1 headers
1 x SPDIF In/out header
1 x HDMI Adapter Audio Cable header
2 x IEEE 1394a headers
1 x COMB header
1 x chassis intrusion header
1 x power LED header
Back Panel Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x parallel port
4 x USB 2.0/1.1 ports
1 x VGA port
1 x IEEE1394a port
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
H/W Monitoring
System voltage detection
CPU / System temperature detection
CPU / System fan speed detection
CPU overheating warning
CPU / System fan fail warning
CPU fan speed control
BIOS
1 8 Mbit flash ROM
Use of licensed AWARD BIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.3, ACPI 1.0b
Form Factor
MicroATX form factor, 244 x 244mm
Other Features
Supports @BIOS
Supports Download Center
Supports Q-Flash
Supports EasyTune5
Supports Xpress Install
Supports Xpress Recovery2
Supports Virtual Dual BIOS

+I/O shield krytka
