SPECS
GENERAL
Dimensions (WxDxH)17.3 in x 17.6 in x 17.6 in
Display TypeCRT monitor / CRT
CRT TypeReal Flat - shadow mask
Native Resolution1920 x 1440 at 60 Hz
Controls & AdjustmentsBrightness, contrast, H/V moire, H/V position, H/V size, sharpness, trapezoid, degauss, pincushion, pin balance, zoom
OSD LanguagesEnglish, German, French, Italian, Spanish
Color Temperature9300K, 6500K, 5500K
Viewable Size18"
Pixel Pitch0.21 mm
Screen CoatingAnti-glare, anti-reflective, anti-static, high contrast coating
Horizontal Refresh Rate97 kHz
Video Bandwidth234 MHz
Vertical Refresh Rate160 Hz
ManufacturerPhilips
CONNECTIVITY
Interfaces1 x VGA - 15 pin HD D-Sub (HD-15)
POWER DEVICE
Nominal VoltageAC 120/230 V
Frequency Required50/60 Hz
Power Consumption Operational100 Watt
POWER
Power Consumption Stand by / Sleep10 Watt
Power Supplyinternal
INTERFACE PROVIDED
Qty1
Connector Type15 pin HD D-Sub (HD-15)
MISCELLANEOUS
OSD LanguagesEnglish, French, German, Italian, Spanish
Controls & AdjustmentsH/V moire, H/V position, H/V size, brightness, contrast, degauss, pin balance, pincushion, sharpness, trapezoid, zoom
MTBF75000 hour(s)
DISPLAY
Video Bandwidth234 MHz
TypeCRT monitor
VIDEO
Video Outputnone
ENVIRONMENTAL STANDARDS
ENERGY STAR CertifiedYes
SYSTEM REQUIREMENTS
OS RequiredMicrosoft Windows 2000, Microsoft Windows 95, Microsoft Windows 98, Microsoft Windows NT
DIMENSIONS & WEIGHT
Width17.3 in
Depth17.6 in
Height17.6 in
Weight46.74 lbs
ENVIRONMENTAL PARAMETERS
Min Operating Temperature32 °F
Max Operating Temperature104 °F
Humidity Range Operating5 - 95%
HEADER
BrandPhilips
Product LinePhilips
Model109B20
Country KitsHong Kong, Taiwan
Packaged Quantity1
CompatibilityMac, PC
PROJECTOR
Max V-Sync Rate160 Hz
Max H-Sync Rate97 KHz
CABLE DETAILS
TypeVGA cable, power cable
Included Qty1
TV TUNER
TV Tuner PresenceNoGENERAL
ManufacturerPhilips
