LGA 775 Socket for Intel® Coreâ¢2 Duo / Pentium® Dual-Core / Pentium® D / Pentium® 4 / Celeron® D Processors with 1066/800 MHz FSB
Supports Intel® Hyper-Threading Technology
Chipset
Intel® 945G / Intel® ICH7 Express Chipset
Memory
2 x 240-pin DIMM sockets support max. memory capacity 2GB
Supports Dual Channel DDR2 667 Un-buffered Non-ECC memory
Graphics
Integrated Intel® Graphics Media Accelerator 950 (Intel® GMA 950 )
LAN
On board 10/100/1000M PCI controller (Gigabit Ethernet)
Audio
On board HD 7.1CH Audio CODEC
Expansion Slots
1 x PCI-E X16 (PCI Express)
1 x PCI-E X1 (Wi-Fi Accessories)
2 x PCI
Internal I/O
1 x Floppy Port supports up to 2.88 MB
1x Ultra DMA 100/66/33 IDE connector
4 x SATA 3Gb/s connector
2 x USB header (support 4 ports)
1 x FP-Audio, 1 x CD-In
Back Panel I/O
1 x PS/2 Keyboard, 1 x PS/2 Mouse
1 x Serial port, 1 x Parallel port, 1 x VGA connector
4 x USB 2.0, 1 x RJ-45 LAN connector
7.1 CH Audio connector (Front, Line-in, MIC-in, Center/Subwoofer, Surround, Rear Surround)
Serial ATA
4 x SATA 3Gb/s offer by Intel® ICH7
Form Factor
Micro ATX form factor 244 x 244mm
PCB Color: Blue
RoHS
100% lead-free process and RoHS compliant
