Supported CPU
CPU Socket Type Socket 478
CPU Type Pentium 4 Prescott / Celeron D
FSB 800/533 MHz
Supported CPU Technologies Hyper-Threading Technology
Chipsets
Chipset Intel 848P
South Bridge Intel ICH5
Onboard Video
Onboard Video Chipset None
Memory
Number of Memory Slots 2x184pin
Memory Standard DDR 400
Maximum Memory Supported 2GB
Expansion Slots
AGP Slots 1 x AGP 4X / 8X
PCI Express x16 None
PCI Slots 5 x PCI Slots
Storage Devices
PATA 2 x ATA100 4 Dev. Max
SATA 1.5Gb/s 2 x SATA 1.5 Gb/s
Onboard Audio
Audio Chipset Realtek ALC655
Audio Channels 6 Channels
Onboard LAN
LAN Chipset Realtek 8100C
Max LAN Speed 10/100Mbps
Rear Panel Ports
PS/2 2
COM 1
LPT 1
USB 1.1/2.0 4 x USB 2.0
S/PDIF Out 1 x Coaxial
Audio Ports 3 Ports
Internal I/O Connectors
Onboard USB 4 x USB 2.0
Physical Spec
Form Factor ATX
Dimensions (W x L) 12" x 8.3"
Power Pin 20 Pin
